HP 571956-B21 24-Port 10Gb Virtual Connect Expansion Module View larger
Previous Next

HP 571956-B21 24-Port 10Gb Virtual Connect Expansion Module

New

In Stock

Managed 24‑port FlexFabric module (16 × internal 10 Gb Ethernet + 8 external SFP+
×




$39.90

  • New
  • Refurbished

Detailed Specifications

HP 571956-B21

Virtual Connect FlexFabric 10 Gb/24‑Port Expansion Module

The HP 571956‑B21 Virtual Connect FlexFabric Expansion Module is a managed network module engineered to deliver converged 10 Gb Ethernet and Fibre Channel (up to 8 Gb) connectivity inside HP blade enclosures. Designed for enterprise environments it enables a simplified, flexible, and efficient blade‑edge topology by reducing the need for separate SAN and LAN switching infrastructure.

Features

Installed in a c7000 or c3000 Enclosure, each module provides backplane connectivity to up to 16 server ports at 10 Gb Ethernet. Four SFP+ external uplinks support either 10 GbE or 8 Gb Fibre Channel, and an additional four external SFP+ slots deliver 10 Gb Ethernet.

Advanced Options

This architecture enables convergence of LAN and SAN traffic over a single module and reduces cabling complexity and hardware overhead. Virtual Connect Manager GUI or CLI offers centralized control and profile-based deployment of network configurations.

Product Key Features

  •  16 internal 10 Gb Ethernet backplane + 8 SFP+ slots (4 for 10 GbE, 4 for 8 Gb FC)

  •  Reduces network sprawl—no need for separate Ethernet and Fibre Channel switches

  •  Managed module with FlexFabric Manager GUI, CLI, SNMP v1/v2 support

  •  Supports VLANs, IGMP snooping, link aggregation (LACP), Wake-on-LAN

  •  Optimized for HP c-Class BladeSystem, Integrity BL860c, ProLiant BL servers

Reliability & Performance

Built to meet enterprise-level reliability, the 571956‑B21 module is hot‑swappable within the blade enclosure. It supports management via SNMP v1/v2, HTTP/HTTPS, and CLI. With IGMP snooping for multicast traffic and link aggregation support (LACP), it ensures efficient and secure traffic management. The MAC address table accommodates up to ~8K entries, and the module integrates Wake-on‑LAN functionality for streamlined server orchestration.

Key Features :

    • 16 × internal 10 Gb Ethernet backplane ports

    • 4 × external 10 Gb Ethernet SFP+ uplinks

    • 4 × external 8 Gb Fibre Channel SFP+ uplinks

    • Managed via Virtual Connect Manager GUI, CLI, SNMP v1/v2

    • Supports VLANs, IGMP snooping, Wake-on‑LAN, Link Aggregation (LACP)

    • MAC address table up to ~8K entries

    • Converged I/O for greater infrastructure efficiency

    • Hot‑swappable blade‑edge module

    • SSL encryption support; LDAP integration

    • Validated for c-Class systems with FlexFabric adapters

SpecificationDetails
Model Number 571956‑B21
Product Type Virtual Connect FlexFabric Expansion Module
Form Factor Blade enclosure plug‑in module
Internal Ports 16 × 10 Gb Ethernet via backplane
External Ethernet Uplinks 4 × 10 Gb Ethernet SFP+ slots
External Fibre Channel Uplinks 4 × 8 Gb Fibre Channel SFP+ slots
Management Interfaces GUI, CLI, SNMP v1/v2, HTTP/HTTPS
Features VLANs, IGMP Snooping, LACP, WOL, SSL, LDAP support
MAC Address Table ~8,000 entries
Routing / Protocols IGMP v2, basic VLAN routing
Supported Systems HP BladeSystem c-Class, Integrity BL860c, ProLiant BL G6 servers
Operating Temp ~10 °C to 35 °C (50 °F to 95 °F)
Humidity Range 10 %–90 %
Dimensions (H×W×D) ~2.8 cm × 28 cm × 19.25 cm (1.1″ × 11″ × 7.6″)
Weight ~1.27 kg (2.8 lb)
Certifications UL, TUV, CISPR/A, VCCI, EN 55022 Class A, IEC 60950-1, CB, WEEE
