Detailed Specifications
HPE S0U75A Aruba CX 5420 8 Port Smart Rate (1/2.5/5/10 Gb) Class 8 PoE Module
Overview
The HPE S0U75A is a high-performance line card for the Aruba CX 5420 modular chassis, offering 8 Smart-Rate RJ-45 ports that support 1G, 2.5G, 5G, and 10G speeds along with Class 8 PoE. This module is designed for access layer environments where you need to deliver both multi-gig connectivity and high PoE power×think modern access points, high-end IP phones, or IoT devices with higher wattage demands. Running under AOS-CX through the 5420 chassis, you retain full Layer-3 routing, automation, and advanced analytics. Being TAA-compliant, it's also suitable for regulated or government deployments.
Key Features
8× Smart-Rate ports (1 / 2.5 / 5 / 10 Gb) × allows multi-gig access per port.
Class 8 PoE × supports up to 90 W per port for high-power devices.
AOS-CX support × full Layer-3 functionality, scripting, ACLs, and routing.
TAA-compliant × ideal for regulated procurement use cases.
Technical Specifications
| Specification | Detail |
|---|
| Brand | HPE / Aruba Networking |
| Part Number | S0U75A |
| Product Type | Modular Switch Line Card |
| Port Configuration | 8 × RJ-45 Smart-Rate (1/2.5/5/10 Gb) |
| PoE Class | Class 8 (up to ~90 W per port) |
| Management / OS | AOS-CX via CX 5420 chassis |
| Minimum Required AOS-CX Software | Version 10.15.0001 |
| Dimensions | 214.7 × 212.2 × 45.15 mm |
| Weight | ~0.76 kg |
| Operating Temperature | 0 °C to 45 °C typical for the 5420 chassis |
| PoE Standards Supported | IEEE 802.3bt (Class 8 |
