Netgear GSM4210PX-100NAS AV Line M4250-8G2XF-PoE Managed Switch
New
In Stock
Warning: Last items in stock!
Availability date:
8-Port PoE+ AV Switch with 10G Uplinks.
×
Detailed Specifications
Netgear GSM4210PX-100NAS AV Line M4250-8G2XF-PoE Managed Switch
Overview
Modernize your office network with smart managed switches and plug-and-play unmanaged options. From compact 5-port switches to scalable 48-port solutions, we support growing businesses with flexible networking hardware. Perfect for SMBs planning an office network upgrade with bulk purchase options and long-term cost efficiency.
The Netgear GSM4210PX-100NAS, a cornerstone of the M4250 AV Line, is a purpose-built managed switch engineered specifically for professional Audio/Video over IP (AVoIP) deployments. Unlike traditional enterprise switches that require extensive manual configuration for multicast traffic, this unit features a dedicated AV-oriented user interface. This interface simplifies the deployment of complex protocols like Dante, AVB, and Q-SYS by providing pre-configured profiles that optimize IGMP Plus and VLAN settings automatically.
Equipped with eight 10/100/1000BASE-T PoE+ ports and two 10G SFP+ fiber uplinks, the GSM4210PX provides a robust 220W power budget to support high-density endpoint environments. Its compact form factor and versatile mounting options×including standard rack ears, VESA mounts, and threaded holes×make it ideal for integration into server rooms, conference tables, or behind displays. The switch operates with intelligent fan control, allowing for fanless operation in temperature-controlled environments or whisper-quiet performance during high PoE loads. This ensures reliable, low-latency data distribution essential for synchronized audio and high-resolution video streaming in corporate, educational, and broadcast settings.
Key Features
Eight 10/100/1000BASE-T PoE+ ports with 220W budget.
Dual 10G SFP+ uplinks for high-bandwidth backhaul.
Pre-configured AV profiles for Dante, NVX, and AVB.
Versatile mounting for racks, walls, or VESA brackets.
Specifications
Brand
Netgear
Part Number
GSM4210PX-100NAS
Product Type
Managed AV Switch
Form Factor
1U Rackmount / Desktop / VESA
Total Ports
10 (8x RJ45, 2x SFP+)
PoE Standard
IEEE 802.3at PoE+ (30W per port)
PoE Power Budget
220W
Switching Capacity
60 Gbps
Forwarding Rate
44.64 Mpps
MAC Address Table
16K entries
Acoustics
Fanless or 28.5dB (at 25°C)
Dimensions
210 x 257 x 40 mm
Weight
1.67 kg
Frequently Asked Questions
Does this switch support Audio Video Bridging (AVB)?
Yes, the M4250 series supports AVB via an optional license, allowing for precise synchronization and low-latency transport in professional audio environments.
Can the fans be turned off for noise-sensitive environments?
The switch features an "off" fan mode for silent operation when the internal temperature and PoE load remain within specific thresholds, making it suitable for in-room placement.
Is the AV UI different from the standard Netgear management interface?
Yes, the AV UI is a simplified, web-based dashboard specifically designed to assign AV profiles to ports without needing deep networking expertise, though a standard IT GUI is also available.
