NETGEAR GS316P-100NAS

16‑Port Gigabit Ethernet Unmanaged PoE+ Switch with FlexPoE

The NETGEAR GS316P‑100NAS is a robust unmanaged Gigabit Ethernet switch with full PoE+ capability, designed for quick and reliable deployment in small offices, retail, or surveillance environments. It powers and connects devices like VoIP phones, wireless access points, and IP cameras—all through a single Ethernet cable.

Features

Featuring a non-blocking switching architecture, the GS316P ensures full 32 Gbps performance across all 16 ports . With a total PoE capacity of 115 W, the switch intelligently distributes power to connected devices up to 30 W per port. Using NETGEAR’s FlexPoE technology, the budget can be upgraded to 183 W using the EPS200W power adapter—no need to replace the switch.

Advanced Options

The fanless design ensures silent operation while the metal housing improves durability. Energy-efficient features like IEEE 802.3az and short-cable detection reduce power use when traffic is light or cables are short.

Product Key Features

  •  16× Gigabit RJ‑45 ports, all supporting PoE+ (up to 30 W each)

  • 115 W total PoE budget, automatically balanced per port

  •  FlexPoE upgradeable to 183 W via optional EPS200W adapter

  •  True plug‑and‑play—no setup or configuration needed

  •  Fanless, silent operation in a rugged metal chassis

  •  Energy-efficient with 802.3az and short‑cable power savings

Reliability & Performance

Equipped with a 4 K MAC address table, 1 MB packet buffer, and non‑blocking 32 Gbps switching, this switch delivers reliable performance with ultra-low latency . Automatic PoE power balancing ensures optimal device operation. Mountable on walls or desks (kit included), the switch is suited for versatile environments. A 3‑year warranty underscores NETGEAR’s confidence in its longevity.

Key Features :

  • 16× Gigabit RJ‑45 ports with PoE+/PoE (802.3at)

  • 115 W total PoE capacity; upgradeable to 183 W via FlexPoE

  • Plug‑and‑play – no configuration needed

  • Silent, fanless metal enclosure

  • Energy efficiency: 802.3az, short‑cable power saving

  • Auto MDI/MDIX, auto speed negotiation

  • Jumbo frame support up to 9,216 bytes

  • Desktop or wall mounting via included kit

SpecificationDetails
Model Number GS316P‑100NAS
Product Type 16‑Port Gigabit Unmanaged PoE+ Switch
Copper Ports 16× 10/100/1000Base‑T (auto MDI/MDIX)
PoE+ Ports All 16 ports (up to 30 W each)
Total PoE Budget 115 W (upgradeable to 183 W via EPS200W adapter)
Switching Capacity 32 Gbps non-blocking
Packet Buffer 1 MB shared buffer
MAC Address Table 4 K entries
Jumbo Frames Up to 9,216 bytes
Energy Features 802.3az, short-cable detection
Power Consumption ~127.9 W max active; ~2.7 W idle
Housing Rugged metal, fanless
Mounting Options Desktop or wall-mount (kit included)
Dimensions (WxDxH) 286×102×27 mm (11.3×4.0×1.1 in)
Weight 0.88 kg (1.94 lb)
