HPE Aruba JL324A 2930M 24 Ports PoE+ 1-slot Ethernet Switch

New

In Stock

HPE Aruba JL324A is a 24-port PoE+ managed Layer 3 switch with 1 modular uplink slot
×




$3,844.00

  • New

Detailed Specifications

HPE JL324A

Aruba JL324A 2930M 24‑Port Smart Rate PoE+ 1‑Slot Ethernet Switch

The Aruba JL324A is a 1U Layer 3 access switch featuring 24 Smart Rate PoE+ ports capable of delivering multigigabit speeds and high PoE power for demanding access-layer environments. Designed for digital workplaces, it supports wired/wireless convergence, unified security, and robust scalability.

Features

Powered by Aruba's ProVision ASIC, the switch offers wire-speed forwarding (112 Mpps throughput, 320 Gbps switching capacity) with ultra-low latency (<3.1 µs at 1 GbE)

Advanced Options

Smart Rate ports enable 1/2.5/5 Gbps speed using existing cabling—perfect for Wi‑Fi 6 APs, edge servers, or high-speed endpoints. Its modular architecture allows stacking up to 10 switches and uplinks via 10 GbE/40 GbE cards. Aruba’s policy-based automation simplifies AP adoption and network segmentation.

Product Key Features

  •  24× Smart Rate PoE+ ports supporting 1/2.5/5 GbE speeds over Cat5e/6

  •  Up to 840 W PoE+ budget, scalable to 1,440 W with dual PSUs

  •  Layer 3 routing & stacking: Static, RIP, OSPF, PIM, IPv6; stack up to 10 units with 100 Gbps backplane

  •  Modular uplink & stacking slots: Add 10 GbE SFP+ or 40 GbE QSFP+ uplinks

  •  Unified wired/wireless management via Aruba Central, ClearPass, AirWave with SDN support (OpenFlow, REST)

  •  Advanced QoS & security: ACLs, 802.1X, MACsec, DHCP snooping, LLDP‑MED, sFlow, dynamic segmentation

Reliability & Performance

The JL324A supports dual modular power supplies and hot-swappable design for redundancy. PoE power can scale from 840 W (single PSU) to 1,440 W (dual PSU), accommodating high‑power devices like IoT endpoints or video equipment Its robust Layer‑3 routing, QoS, and security features ensure enterprise-grade performance.

Key Features (Bullet List)

  • 24 × autosensing 1/2.5/5 GbE Smart Rate PoE+ ports

  • Modular uplink slot (10 GbE SFP+ / 40 GbE QSFP+)

  • Stacking module slot for up to 10-unit stacks

  • 320 Gbps switching capacity, 112 Mpps throughput

  • Stack backplane: 100 Gbps

  • Layer 3 routing: static, RIP v1/v2/ng, OSPF v2/v3, PIM, VRRP, IPv6

  • PoE budget: 840 W (single PSU), 1,440 W (dual PSUs)

  • Enhanced security: 802.1X, MACsec, ACLs, DHCP snooping, dynamic segmentation

  • SDN: REST API, OpenFlow 1.0/1.3

  • Management: CLI, Web GUI, SNMP, Aruba Central, ClearPass, AirWave

SpecificationDetails
Model Number JL324A
Type Layer 3 Managed Stackable Switch (1U)
Ports 24 × 1/2.5/5 GbE Smart Rate PoE+ RJ‑45
Uplink Slot 1 modular slot (10 GbE SFP+ / 40 GbE QSFP+)
Stacking Slot 1 (up to 10 units; 100 Gbps backplane)
Switching Capacity 320 Gbps
Forwarding Rate 112 Mpps
Latency (1 GbE) <3.1 µs
PoE Power Budget 840 W (single), 1,440 W (dual PSU)
Power Supplies Dual modular PSUs (sold separately)
Routing Protocols Static, RIP v1/v2/ng, OSPF v2/v3, PIM, VRRP
Stack & Uplink Modules Support for 10/40 GbE modules
Security & QoS 802.1X, MACsec, ACLs, DHCP snooping, LLDP‑MED, sFlow, QoS
SDN & APIs REST, OpenFlow 1.0/1.3
Management Aruba Central, ClearPass, AirWave, CLI, GUI, SNMP
Dimensions (W×D×H) 17.4″ × 12.8″ × 1.7″ (44.3 × 32.4 × 4.4 cm)
Weight ~4.5 kg (9.92 lb)
Warranty Aruba Limited Lifetime
