Detailed Specifications
INTELLINET 508995 - Industrial 4-Port Gigabit PoE++ Switch
Overview :
The INTELLINET 508995 Industrial 4-Port Gigabit Ethernet PoE++ Switch provides high-power data and power delivery for harsh industrial environment deployments.
Featuring an IP40-rated metal housing, it operates in wide temperatures (-20°C to 75°C).It includes 4 Gigabit PoE++ ports (up to 95W per port, 240W total budget) and 2 SFP slots for fiber uplinks.With redundant DC inputs, 6 kV surge protection, and DIN-rail mounting, it ensures reliable network uptime.
Key Features :
4 Gigabit PoE++ ports with up to 95W output per port (IEEE 802.3bt).
2 SFP slots for long-distance fiber connections.
Hardened IP40 metal casing with DIN-rail mount bracket (-20°C to 75°C).
Redundant DC power inputs, 6 kV surge protection, and 15 kV ESD protection.
Specifications :
| Attribute | Specification |
| Brand | INTELLINET |
| Part Number | 508995 |
| Alphanumeric Part Number | IIS-4G02POE-240W |
| Product Type | Industrial 4-Port Gigabit PoE++ Switch with 2 SFP Ports |
| Network Type | Unmanaged Layer 2 Ethernet |
| Total Ports | 6 Ports (4x RJ45 PoE++ + 2x SFP) |
| Max Output Per Port | Up to 95 W |
| Total PoE Budget | Up to 240 W |
| Input Voltage | Dual Redundant 48.0-57.0 V DC |
| Housing Rating | IP40 Metal / DIN-Rail Mount |
| Operating Temp | -20°C to 75°C (-4°F to 167°F) |
