Detailed Specifications
Intellinet 561228 - 8-Port Web-Managed PoE+ Switch
Overview:
The Intellinet 561228 is an 8-port web-managed Gigabit Ethernet switch with Power over Ethernet Plus (PoE+) capabilities and 2 additional SFP uplink ports, designed for intelligent edge connectivity in small-to-medium enterprise and branch office networks . Network administrators use this Layer 2 switch to power and manage connected devices while gaining remote control through a web-based interface .
This switch solves the challenge of powering and managing PoE devices such as IP cameras, VoIP phones, and wireless access points without requiring a complex enterprise-grade chassis switch . Technical capability includes a 5.6 Gbps switching fabric, 1K MAC address table, 64 KB packet buffer memory, and support for VLANs, QoS, and IGMP snooping . The two SFP slots provide fiber uplinks for extended reach beyond standard 100m copper cable limitations .
Deployment is in a desktop or 1U rack-mountable metal chassis . The switch includes 8 PoE+ ports with a total power budget of 95W (up to 30W per port) . Management features include SNMP v1/v2c, RMON, and port mirroring for network monitoring . The switch does not support advanced Layer 3 routing features and is not suitable for core network deployments requiring 10G uplinks .
Key Features:
8x Gigabit PoE+ ports with 30W per port
2x dedicated SFP slots for fiber uplinks
Web-managed with VLAN, QoS, and IGMP snooping
95W total PoE budget, 5.6 Gbps switching capacity
Desktop or rack-mountable with fanless design
Specifications:
| Specification | Value |
|---|
| Brand | Intellinet Network Solutions |
| Part Number | 561228 |
| Product Type | Web-Managed Gigabit PoE+ Switch |
| RJ45 Ports | 8 x 10/100/1000 Mbps (Auto-MDIX) |
| PoE Ports | 8 (IEEE 802.3at/af) |
| Max Power per Port | 30 W |
| Total PoE Budget | 95 W |
| SFP Slots | 2 x Gigabit SFP (dedicated uplinks) |
| Switching Capacity | 5.6 Gbps |
| MAC Address Table | 1,000 entries |
| Packet Buffer | 64 KB |
| Jumbo Frames | Up to 9 KB |
| Management | Web GUI, SNMP v1/v2c, RMON, Port Mirroring |
| VLAN Support | Tag-based and port-based |
| Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1p, 802.1q, 802.3af, 802.3at |
| Power Supply | Internal AC 100-240V, 50-60 Hz |
| Max Power Consumption | 102 W (full load) |
| Form Factor | Desktop or 1U rack-mountable |
| Housing | Metal |
| Cooling | Fanless |
| Operating Temp. | 0°C to 40°C |
| Operating Humidity | 10-90% RH, non-condensing |
| Certifications | FCC Class A, CE, RoHS |
