Detailed Specifications
HPE JL383A OfficeConnect 1920S 8G PPoE+ 65 W Switch
Overview
The HPE JL383A is an 8-port gigabit smart-managed switch designed for small-business edge and access-layer deployments where a compact form-factor and limited PoE budget suffice. It includes eight RJ-45 10/100/1000 Mbps ports, of which four support PoE+/PoE with a total power budget of 65 W, enabling deployment of IP phones, wireless access points or surveillance cameras in a compact switch. With a switching fabric of 16 Gbps and forwarding up to 11.9 Mpps, it suits small wiring closets, branch office racks or dense desktop installations. Management is via web GUI, SNMP or CLI, and the device supports basic Layer 2 plus lite Layer 3 static routing (up to 32 routes) and IPv6 host mode×fitting into existing network monitoring systems without requiring core-level features.
Key Features
Eight RJ-45 ports including four PoE+/PoE-capable with 65 W total budget.
16 Gbps switching capacity and up to 11.9 Mpps packet forwarding.
Smart-managed features: VLANs, ACLs, IPv6 host mode, and static routing (32 routes).
Compact 1 U form-factor (1.73 in height) for desktop, wall- or rack-mount use.
Idle power consumption around 9.7 W, maximum up to ~72.9 W with PoE and full load.
Technical Specifications
| Specification | Value |
|---|
| Brand | HPE |
| Part Number | JL383A |
| Product Type | OfficeConnect 1920S 8G PPoE+ Switch |
| Access Ports | 8 × 10/100/1000 Mbps RJ-45 |
| PoE-Capable Ports | 4 of the 8 ports support PoE+/PoE |
| PoE Budget | 65 W |
| Switching Capacity | 16 Gbps |
| Forwarding Rate | Up to 11.9 Mpps (64-byte packets) |
| Dimensions (H × W × D) | 1.73 in × 10.0 in × 6.28 in |
| Weight | ~2.01 lbs |
| Maximum Power Consumption | ~72.9 W |
| Idle Power Consumption | ~9.7 W |
| Latency | < 7 µs at 100 Mb/s; < 2.3 µs at 1000 Mb/s |
| Static IPv4 Routes Supported | Up to 32 |
| Jumbo Frame Support | Up to 9,216 bytes |
| Operating Temperature | 0 °C to 40 °C |
