Detailed Specifications
Eaton NGI-U04C2P4-4 4-port industrial unmanaged Gigabit Ethernet switch
Overview
The Eaton NGI-U04C2P4-4 is an unmanaged industrial Ethernet switch designed for industrial automation, IP surveillance, transportation, and edge network deployments requiring Gigabit connectivity with Power over Ethernet support.
The switch provides four 10/100/1000 Mbps Gigabit Ethernet PoE+ ports with support for powering connected devices such as IP cameras, wireless access points, sensors, and industrial controllers through the Ethernet cabling infrastructure. Dual Gigabit SFP uplink interfaces support fiber or copper backbone connectivity for extended industrial network deployments.
Its hardened metal enclosure and DIN-rail mounting design support installation in factory automation cabinets, utility infrastructure, warehouse environments, and outdoor industrial enclosures. The switch operates in extended temperature conditions and supports industrial-grade vibration and shock resistance.
The NGI-U04C2P4-4 is suitable for compact industrial Ethernet deployments where unmanaged plug-and-play switching and PoE device connectivity are required. It is compatible with IEEE 802.3af and 802.3at powered devices and standard Gigabit Ethernet infrastructure.
This model is not intended for advanced Layer 2/Layer 3 traffic management, enterprise aggregation, or high-density core switching environments.
Key Features
- 4× Gigabit PoE+ Ethernet access ports
- Dual SFP uplinks for fiber connectivity
- Industrial DIN-rail hardened metal housing
- Supports IEEE 802.3af and 802.3at PoE
- Fanless operation for harsh environments
Specifications
| Specification | Details |
|---|
| Brand | Eaton |
| Part Number | NGI-U04C2P4-4 |
| Product Type | Unmanaged Industrial Ethernet Switch |
| Ethernet Ports | 4 × 10/100/1000 Mbps RJ45 PoE+ |
| SFP Ports | 2 × Gigabit SFP |
| PoE Standard | IEEE 802.3af / 802.3at |
| PoE Power Per Port | Up to 30 W |
| Switching Capacity | 10 Gbps |
| MAC Address Table | 8000 entries |
| Mounting Type | DIN Rail |
| Housing Type | Industrial Metal Enclosure |
| Power Input | 24-57VDC Terminal Block |
| Operating Temperature | -10°C to 60°C |
| Network Standards | IEEE 802.3, 802.3ab, 802.3af, 802.3at |
| Compliance | CE, FCC, RoHS, REACH, TAA |
