Detailed Specifications
HPE JG299A 3600-24 v2 EI Layer-3 Managed Switch
Overview
The HPE JG299A (3600-24 v2 EI) is a rack-mountable, managed switch that provides 24 10/100Base-TX ports, along with 4 SFP uplink ports and 2 shared gigabit ports. It supports Layer-3 functions such as static routing, OSPF, RIP, VRRP, and IPv6 routing, making it suitable for edge, branch, or enterprise access deployments. The switch is stackable, supports ACLs, QoS, and comes with HPE's management options for scalable enterprise networks.
Key Features
24 × 10/100Base-TX access ports
4 × 1 Gb SFP uplink ports + 2 × shared gigabit ports
Layer-3 routing: OSPF, RIP, static IPv4/IPv6, VRRP
Stackable architecture for resilient, scalable networks
Management: CLI, web GUI, SNMP, RADIUS/LDAP authentication, SSL/SSH security
Technical Specifications
| Specification | Details |
|---|
| Brand | HPE / HP |
| Part Number | JG299A |
| Product Type | Managed Layer-3 Ethernet Switch |
| Access Ports | 24 × 10/100Base-TX |
| Uplink Ports | 4 × 1 Gb SFP + 2 × shared 10/100/1000 |
| Switching Capacity | 12.8 Gbps |
| Forwarding Performance | 9.5 Mpps |
| Memory | 256 MB SDRAM, 128 MB Flash |
| Jumbo Frame Support | Up to 9,216 bytes |
| Routing Protocols | OSPF, RIP-1/2, VRRP, Static IPv4 & IPv6, ECMP, BGP-4+ |
| Security Features | ACLs, 802.1X, SSH, SSL, RADIUS, LDAP |
| Quality of Service | 8 hardware queues, traffic prioritization |
| Stacking | Yes (stackable with compatible units) |
| Power Input | Internal AC power supply |
| Dimensions | 1U rack form factor |
| Operating Temperature | 0°C - 50°C |
