HPE J9979A OfficeConnect 1820 Ethernet Switch 8 Ports View larger

HPE J9979A OfficeConnect 1820 8G Ethernet Switch

J9979A

New

"8-Port GigE L2 Smart-Managed Switch"

×




Detailed Specifications

HPE J9979A OfficeConnect 1820 8G Ethernet Switch

Overview

The HPE J9979A OfficeConnect 1820 8G is a smart-managed, fixed-configuration Gigabit Ethernet Layer 2 switch designed for small businesses that require key networking features in an easy-to-administer solution. It addresses the need for reliable, gigabit-speed network connectivity without the complexity of fully managed hardware. This switch is ideal for deployment in small office environments, retail locations, or any organization seeking fundamental network control with minimal IT overhead. This device provides essential Layer 2 capabilities, including VLANs for traffic segmentation, link aggregation for increased bandwidth, and Quality of Service (QoS) policies to prioritize time-sensitive data like VoIP and video traffic. Operation is streamlined through an intuitive web browser interface, allowing even non-technical users to configure and monitor the network effectively. The fanless design ensures silent operation, a critical benefit for placement in open office areas. Engineered for flexible installation, the J9979A has a compact form factor that can be mounted on a wall, under a table, or placed on a desktop. A unique feature is its ability to be powered by an upstream Power over Ethernet (PoE) switch via its first port, eliminating the need for a dedicated power adapter in locations where power outlets are scarce. This makes it a versatile choice for extending network access in challenging physical environments.

Key Features

  • Simple web-based management for non-technical users.
  • Fanless design ensures completely silent operation.
  • Flexible mounting options: desktop, wall, under-table.
  • Can be powered by an upstream PoE switch via Port 1.
  • Layer 2 feature set includes VLANs and link aggregation.

Specifications

SpecificationValue
Brand HPE
Part Number J9979A
Product Type Smart-Managed Layer 2 Switch
Total Ports 8x 10/100/1000 Gigabit Ethernet
Switching Capacity 16 Gbps
Throughput Up to 11.9 Mpps
MAC Address Table Size 8,000 entries
Memory and Processor ARM Cortex-A9 @ 400 MHz, 128 MB SDRAM
Flash Memory 16 MB
Form Factor Desktop, Wall-Mountable (1U height)
Power Consumption 12.2 W (maximum)
Acoustic 0 dB (Fanless)
Management Web Browser Interface
Jumbo Frame Support 9,220 bytes
