HPE R9L64-61001 5140 48G PoE+ 4SFP+ 1-slot Ethernet Switch

New

48-port PoE+

×




  • New

Detailed Specifications

HPE R9L64-61001

FlexNetwork 5140 48G PoE+ 4SFP+ 1-Slot HI Managed Ethernet Switch

The HPE R9L64-61001 FlexNetwork 5140 HI Switch delivers high-performance Layer 3 Switch networking with 48 PoE+ Gigabit ports and 4 SFP+ uplinks, designed to meet the demands of growing enterprise LAN environments. It provides intelligent management, flexibility, and scalability for advanced campus networking.

Features

Part of the HPE FlexNetwork 5140 HI Switch Series, this model offers robust enterprise-grade switching with simplified management and enhanced security. With 48 PoE+ ports and 4 SFP+ uplinks, it's built to power connected devices such as access points, IP phones, and surveillance systems while supporting high-speed aggregation or uplinks through SFP+.

Advanced Options

This switch supports an optional expansion slot for modular uplink or stacking modules, making it ideal for dynamic environments that demand scalability and performance. Advanced Layer 3 Switch capabilities, including static routing, RIP, OSPF, and BGP, ensure seamless integration into complex network topologies.

Product Key Features

  •  48 × Gigabit PoE+ ports with high power budget

  •  4 × 1/10GbE SFP+ uplink ports for high-speed connectivity

  •  Intelligent Management Center (IMC) compatible for centralized control

  •  Flexible modular design with 1 expansion slot

  •  Layer 2 and Layer 3 Switch  advanced features for enterprise networking

  •  Ideal for mid-size and large campus networks

Reliability & Performance

Built with HPE Intelligent Resilient Fabric (IRF) stacking technology, this switch ensures high availability and simplified management across multiple units. Its hot-swappable architecture, redundant power compatibility, and support for jumbo frames and QoS ensure optimal performance even in high-traffic scenarios. With enterprise-grade PoE+ support, it's ready to deliver both data and power with maximum efficiency.

Key Features :

  • 48 × 10/100/1000BASE-T PoE+ ports

  • 4 × SFP+ 10GbE uplink ports

  • 1 expansion slot for additional modules

  • IRF support for up to 9 switches

  • Layer 2/3 switching, static and dynamic routing

  • ACLs, QoS, and MACsec for enhanced network security

  • Intelligent Management Center (IMC) integration

  • Energy-efficient with fan and thermal management

SpecificationDetails
Model Number R9L64-61001
Series HPE FlexNetwork 5140 HI
Product Type Layer 3 Switch Managed Ethernet Switch
Ports 48 × 10/100/1000BASE-T PoE+, 4 × 10GbE SFP+
Expansion Slot 1 × module slot (for stacking/uplinks)
Switching Capacity 176 Gbps
Forwarding Rate 131 Mpps
PoE Budget Up to 740W (with appropriate power supplies)
Stacking Support IRF (up to 9 devices)
Management Web, CLI, SNMP, RMON, IMC
Layer 3 Switch Protocols Static Routing, RIP, OSPF, BGP
Security Features MACsec, ACLs, 802.1X, DHCP Snooping
Form Factor 1U Rackmountable
Power Supply Redundant PSU support (modular)
Cooling Intelligent fan system
