HPES3500-48P

Aruba-48P 48-Port PoE+ Layer 2 Managed Ethernet Switch

The HPEAruba S3500-48P is a fully managed Layer 2 Managed Ethernet Switch featuring 48 Gigabit PoE+ ports and 4 dedicated SFP uplinks, designed to deliver high-density, power-efficient network connectivity at the edge. With enterprise-grade features and a 370W PoE+ budget, it's perfect for powering access points, IP phones, and surveillance systems in SMB and campus environments.

Features

Engineered for simplified network expansion and centralized control, the Aruba S3500-48P delivers seamless edge access with robust security, traffic prioritization, and easy deployment. Each of the 48 RJ-45 ports supports PoE+ (IEEE 802.3af/at) to power endpoint devices without separate power lines, while the four SFP uplinks ensure high-speed aggregation back to the core.

Advanced Options

Backed by a non-blocking 176 Gbps switching fabric and forwarding performance of ~131 Mpps, this switch provides reliable and efficient data transmission. Ideal for small enterprises, school networks, and branch offices, it supports VLANs, ACLs, QoS, and intuitive management via CLI, Web GUI, or SNMP.

Product Key Features

• 48 Gigabit Ethernet PoE+ ports with 370W total power budget

• Managed Layer 2 switch with static routing and advanced security

• 176 Gbps switching capacity and 131 Mpps forwarding performance

• 4 dedicated SFP uplink ports for flexible network expansion

• Ideal for edge deployments in offices, schools, and retail

• Supports jumbo frames, QoS, and robust traffic management tools

---

Reliability & Performance

With support for jumbo frames, dynamic ARP inspection, and multiple management interfaces, the S3500-48P ensures consistent and secure network operations. Its internal power supply and fan-cooled 1U rackmount chassis offer reliable uptime under typical office and commercial operating conditions. Built to integrate seamlessly with Aruba's management solutions, this switch scales easily within distributed and centralized topologies.

Key Features :

• • 48 × 10/100/1000BASE-T PoE+ ports

  • 4 × 1GbE SFP uplink ports

  • PoE+ support up to 370W total power budget

  • Layer 2 switching with static routing support

  • 176 Gbps switching capacity / 131 Mpps forwarding rate

  • Web GUI, CLI, SNMP v1/v2/v3 management interfaces

  • Jumbo frame support up to 9,220 bytes

  • MAC address table: ~12,000 entries

  • QoS, VLAN, ACL, and port security

  • 1U rackmount form factor with internal power supply

Specification	Details
Model Number	JW662A (S3500-48P)
Product Type	Layer 2 Managed Ethernet Switch
Port Count	48 × 10/100/1000BASE-T PoE+
Uplink Ports	4 × 1GbE SFP slots
Switching Capacity	176 Gbps
Forwarding Rate	~131 Mpps
PoE Budget	Up to 370W (IEEE 802.3af/at)
Management	CLI, Web GUI, SNMP v1/v2/v3
Jumbo Frame Support	Up to 9,220 bytes
MAC Address Table	~12,000 entries
Operating Temperature	0°C to 45°C
Power Supply	Internal (AC), fixed
Dimensions	17.4″ × 14.9″ × 1.7″ (44.2 × 37.9 × 4.3 cm)
Weight	11.6 lbs (5.26 kg)
Mounting	1U Rackmount
