HPEJW662A

ArubaS3500-48P 48-Port Gigabit PoE+ Mobility Access Ethernet Switch

The HPEJW662A ArubaS3500-48P is a high-performance, modular PoE+ access Ethernet Switchwith 48 Gigabit PoE+ ports and optional uplink stacking. Designed for wired-wireless integration in Aruba-managed environments, it delivers enterprise-grade access control, security, and gigabit performance in a scalable form factor.

Features

Part of the ArubaS3500 Mobility Access family, the S3500-48P supports secure, role-based wired access by tunneling traffic to an ArubaMobility Controller for centralized policy enforcement×similar to Arubawireless architecture. It offers flexible wired deployments with auto-MDI/MDIX, LCD display, out-of-band management port, and USB for config backup/import/export

Advanced Options

Uplink module support enables stacking via Aruba×up to eight S3500s can form a logical stack with up to 40 Gb stacking bandwidth. Dual power supply options (600 W or 1,050 W) add redundancy for PoE-heavy deployments

Product Key Features

• • 48 × 10/100/1000 Mbps RJ-45 PoE+ ports (IEEE 802.3af/at)

  • Up to 370 W total PoE power budget

  • Layer 2 switching with static Layer 3 routing and advanced QoS

  • Optional uplink module for 1 Gb or 10 Gb SFP/SFP+ stacking/uplinks

  • Fanless design for quiet, energy-efficient operation

  • Role-based wired access with ArubaMobility Controller support for identity-based policy enforcement

---

Reliability & Performance

The S3500-48P delivers 176 Gbps switching capacity and up to 131 Mpps forwarding rate, with support for jumbo frames up to 9,216 bytes and MAC table size of 12,000 entries . Compliance with Arubaand a limited hardware lifetime warranty ensure service and longevity. With fanless operation and low-power design, it's suitable for quiet office environments or wiring closets

Key Features :

• 48 × autosensing Gigabit PoE+ RJ-45 ports

• PoE+ support (IEEE 802.3af/at), up to 370 W PoE budget

• Layer 2 features: VLANs, STP/RSTP/MSTP, link aggregation, QoS, ACLs

• Static IPv4/IPv6 routing support

• Role-based access enforcement via ArubaMobility Controller

• Modular uplink slot for 4×1 Gb or 10 Gb SFP/SFP+

• Stackable via Aruba(up to eight devices)

• Fanless, silent operation

• Web GUI, CLI, SNMP management, console port, LCD interface

Specification	Details
Part Number	JW662A (ArubaS3500-48P)
Port Count	48 × 10/100/1000BASE-T PoE+
PoE Standard & Budget	IEEE 802.3af/at, up to 370 W total
Switching Capacity	176 Gbps
Forwarding Rate	~131 Mpps
MAC Table Size	~12,000 entries
Jumbo Frames	Supports up to 9,216 bytes
Layer Support	Layer 2 switching + static IPv4/IPv6 routing
Uplink Module Slot	Optional 4-port SFP/SFP+ uplink module (1/10 Gb)
Stacking Support	Arubaup to 8 units
Management Ports	Console (RJ-45), Out-of-band GbE, USB interface, LCD front panel
Security & Features	Role-based access, ACLs, QoS, ArubaMobility Controller integration
Form Factor / Cooling	1U rack-mount, fanless design
Power Supply	Internal 600 W (redundant optional 1,050 W)
Weight / Dimensions	~17.5 lb (8 kg); 44.5 × 44.5 × 4.4 cm
Operating Temp/Humidity	0 °C-50 °C; 5-95% non-condensing humidity
