HPE R9W91A Networking 8100-48XF4C BF3F2ACBDL PL-NV View larger

HPE R9W91A Networking 8100-48XF4C BF3F2ACBDL PL-NV

New

HPE R9W91A 8100-48XF4C: 48-port, 4-uplink switch for enterprise networking
×




  • New

Detailed Specifications

HPE R9W91A Ethernet Switch

Overview :

The Aruba CX 8100 Switch Series offers a flexible and innovative approach to addressing the application, security, and scalability demands of the mobile, cloud, and IoT era. These switches serve the needs of the next-generation core and aggregation layer of campuses, as well as virtual and highly dynamic data center environments. They provide up to 1.76 Tbps of capacity, with line-rate Gigabit Ethernet interfaces including support for Smart Rate (1/2.5/5 Gbps), 10Gbps, 25Gbps, 40Gbps, and 100Gbps.

The CX 8100 series includes industry-leading line rate ports with 1/10GbE (SFP/SFP+) and 40/100GbE (QSFP+/QSFP28) connectivity in a compact 1U form factor. 4x10Gbps and 4x25Gbps break out from 40/100G ports offer advanced flexibility in connectivity and aggregation.

These switches deliver a fantastic investment for customers requiring 1GbE/10GbEwith a mix of fiber and copper ports, and 40/100GbE uplink ports.

PRODUCT DIFFERENTIATORS

The Aruba CX 8100 switch series is based on ArubaOS-CX, a modern, database-driven operating system that automates and simplifies many critical and complex tasks. The enhanced capabilities of ArubaOS-CX provide a unique set of differentiators for campus and data center switching.

Modular Architecture with native cloud-native ArubaOS-CX

AOS-CX operating system features are organized into Aruba CX Foundation and Aruba CX Advanced software licenses. Every Aruba CX switch includes an active, embedded Aruba CX Foundation license at no additional cost with the option to upgrade to an Aruba CX Advanced license.

The CX Foundation license has everything needed to deploy, connect, and troubleshoot an enterprise network, including:

  • Aruba Network Analytics Engine (NAE)
  • Dynamic Segmentation
  • High Availability and Resiliency
  • Quality of Service (QoS)
  • Layer 2 Switching
  • Layer 3 Services and Routing
  • IP Multicast
  • Network Security
  • Support for Aruba NetEdit

The Aruba CX Advanced license includes Aruba CX Edge Insights, offering flow capture from layer 4 to layer 7.

For more information on the CX Advanced License, read the Aruba CX Switch License Ordering Guide

Specifications :

Product Name HPE Networking 8100-48XF4C BF3F2ACBDL PL-NV
Manufacturer Part Number R9W91A#ABA
Product Type Ethernet Switch
Manageable Yes
Ethernet Technology 10 Gigabit Ethernet

100 Gigabit Ethernet
Product Family CX 8100
Media Type Supported Optical Fiber
Total Number of Expansion Slots 52.0
TAA Compliant Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Expansion Slot Type SFP+

QSFP28
Form Factor Surface Mount

Cabinet Mount

Rack-mountable
Power Consumption 450 W
Power Source AC

Power Supply
Layer Supported 3
Environmentally Friendly Yes
Number of Power Supplies Supported 2
Number of SFP+ Slots 48
Modular Yes
Uplink Port Yes
Port / Expansion Slot Details 48 x 10 Gigabit Expansion Slot

4 x 100 Gigabit Expansion Slot
Height 1.7"
Width 17.4"
Depth 16"
Product Series CX 8100
Product Model 48XF4C
Network Technology 10GBase-X

100GBase-X
Input Voltage 120 V AC

230 V AC
Limited Warranty Lifetime
Frequency 50 Hz

60 Hz
