Detailed Specifications
RUCKUS ICX8200-48ZP2-E – Multigig PoE++ Campus Switch
Overview :
The RUCKUS ICX8200-48ZP2-E is a 48-port multigigabit access switch that serves network engineers deploying next-generation campus, branch or edge infrastructures with PoE++-powered devices. It supports 32 ports of standard 10/100/1000 Mbps PoE+ and 16 ports of 100/1000/2.5 Gbps RJ-45 PoE++ (up to 90 W per port), enabling connectivity and power delivery to devices such as Wi-Fi 6/6E/7 access points, multigig cameras and IoT aggregation nodes. With four 1/10/25 GbE SFP28 uplink/stacking ports, it integrates into high-capacity stacks of up to 12 switches and delivers up to 1480 W of total PoE budget in dual-PSU configuration. The device fits into rack-mount edge or access layer deployments in campus or large branch environments. It integrates with RUCKUS management platforms and supports VXLAN, full L2/L3 routing, hot-swappable PSUs/fans, and stacking for streamlined network operations.
Key Features :
32 × RJ-45 10/100/1000 Mbps PoE+ ports for edge devices
16 × RJ-45 100/1000/2500 Mbps PoE++ ports (up to 90 W each)
4 × 1/10/25 GbE SFP28 uplink/stack ports for high-speed backbone
Up to 1480 W total PoE budget with dual redundant power supplies
Specifications
| Spec | Value |
|---|
| Brand | RUCKUS |
| Part Number | ICX8200-48ZP2-E |
| Product Type | Multigig PoE++ Campus Access Switch |
| Switching Capacity (max) | 296 Gb/s |
| Uplink/Stack Ports | 4 × 1/10/25 GbE SFP28 |
| Downlink Ports | 32 × 10/100/1000 Mbps RJ-45 PoE+ + 16 × 100/1000/2500 Mbps RJ-45 PoE++ |
| Max PoE Power Budget | 1480 W (dual PSU configuration) |
| Stackable to | Up to 12 switches |
| Forwarding Capacity‡ | (Model dependent) ~254 Mpps |
| Dimensions (H × W × D) | 1.7″ × 17.3″ × 14.6″ |
| Weight (approximate) | 14.64 lbs |
| Hot-swappable PSUs/fans | Yes |
