NETGEAR XSM4340V-100NES M4350-24X8F8V Switch L3 managed Switch View larger

Netgear XSM4340V-100NES 24-Port 10G SFP+ Managed AV Switch

New

In Stock

24-Port 10G SFP+ AV over IP Switch
×




$4,800.00

  • New

Detailed Specifications

Netgear XSM4340V-100NES 24-Port 10G SFP+ Managed AV Switch

Overview

The Netgear XSM4340V-100NES, part of the M4350 series (M4350-24X4V), is a high-performance Layer 3 managed switch engineered specifically for high-density 10G fiber networking and Pro AV-over-IP environments. It addresses the bandwidth and latency requirements of modern media distribution by providing 24 dedicated 10G SFP+ ports and four 25G SFP28 uplink ports. This configuration ensures a non-blocking fabric capable of handling uncompressed video, high-fidelity audio, and massive data transfers without frame loss or jitter.

Designed for deployment in broadcast studios, large-scale campus backbones, and enterprise edge locations, the XSM4340V simplifies complex multicast configurations through NETGEAR IGMP Plus. This feature automates the setup of AV-over-IP protocols, significantly reducing deployment time for engineers. The switch integrates seamlessly with the NETGEAR Engage Controller for centralized management of AV-oriented VLANs and profiles. With a 680 Gbps switching capacity and robust L3 routing features, it serves as a reliable aggregation point for high-speed fiber networks where low-latency performance is non-negotiable.

Key Features

- 24x 10G SFP+ ports for high-density fiber connectivity.
- 4x 25G SFP28 uplinks to eliminate backbone bottlenecks.
- Pre-configured for out-of-the-box AV-over-IP performance.
- NETGEAR IGMP Plus for automated multicast configuration.

Specifications

Brand Netgear
Part Number XSM4340V-100NES
Product Type Managed L3 Switch (M4350-24X4V)
Total Ports 28
10G SFP+ Ports 24
25G SFP28 Uplink Ports 4
Switching Capacity 680 Gbps
Throughput 505.92 Mpps
Latency (10G SFP+) < 0.82 µs
MAC Address Table 16K
Power Consumption 64.1 W (Max)
Dimensions 440 x 400 x 43.2 mm
Weight 6.34 kg
Operating Temperature 0° to 50° C

Frequently Asked Questions

Does this switch support Power over Ethernet (PoE)?

No, the XSM4340V-100NES is an all-fiber SFP+ model designed for high-speed data and AV transport; it does not provide PoE power.

Is this switch compatible with Dante and SDVoE protocols?

Yes, the M4350 series is specifically certified for Pro AV protocols including Dante, AVB, and SDVoE, featuring pre-configured profiles for these technologies.

Can the 25G SFP28 uplink ports be used with 10G modules?

Yes, the SFP28 ports are backward compatible with 10G SFP+ transceivers and DAC cables if 25G speeds are not required for your current infrastructure.

How is the cooling managed on this unit?

The switch features intelligent fan speed control that adjusts based on internal temperature, allowing for quieter operation in noise-sensitive environments.
