The Ubiquiti UACC-CABLE-PATCH-EL-C6A-3M-W is a 3 m UniFi Premium Patch Cable designed for 10 GbE Ethernet networking. It features a braided thermoplastic elastomer jacket, stranded copper conductors, and translucent booted shielded RJ45 connectors designed to optimize Etherlighting brightness on compatible Ubiquiti equipment.
Ethernet Connectivity
This Cat6A patch cable provides pre-terminated RJ45 connectivity for compatible Ethernet equipment. Its 3 m end-to-end length provides additional reach for connections between network switches, gateways, access points, patch panels, and other RJ45 Ethernet devices.
Etherlighting Connector Design
The translucent booted RJ45 connectors are designed for optimal Etherlighting brightness when connected to compatible Ubiquiti equipment. The cable uses a UTP shielding configuration and stranded copper conductors.
Key Features
- 3 m end-to-end Cat6A patch cable
- Supports data rates up to 10 GbE
- Translucent booted shielded RJ45 connectors for Etherlighting visibility
- Braided TPE jacket with a 3 mm outer diameter
- Supports PoE up to PoE+++ and meets TIA/EIA-568-B.2 and ISO/IEC 11801 standards
Applications
The UACC-CABLE-PATCH-EL-C6A-3M-W is intended for indoor Ethernet installations requiring a 3 m pre-terminated Cat6A connection. It can be used to connect compatible RJ45 network equipment where 10 GbE connectivity and Etherlighting-compatible connectors are required.
DC Supplies Product Note
The 3 m version uses the 3 mm jacket diameter specified for the 0.15–8 m lengths in this product family. Its minimum bend radius is 24 mm, which should be considered when routing the cable around network equipment and within cable-management spaces.
Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number / MPN | UACC-CABLE-PATCH-EL-C6A-3M-W |
| Product Type | Cat6A Ethernet Patch Cable |
| Product Family | UniFi Premium Patch Cable |
| Cable Length | 3 m (9.8 ft), end-to-end |
| Color | White |
| Supported Data Rate | 10 GbE |
| Supported PoE Type | Up to PoE+++ |
| Connectors | 2 × translucent booted shielded RJ45 |
| Operating Environment | Indoor |
| Jacket Material | Thermoplastic elastomer (TPE) and braided |
| Jacket Diameter | 3 mm (0.11 in) |
| Shielding Type | UTP |
| Conductor Type | Stranded copper |
| Conductor Wire Gauge | 34 AWG |
| Minimum Bend Radius | 24 mm (0.94 in) |
| Flame Rating | VW-1 (UL1581) |
| Standards | TIA/EIA-568-B.2; ISO/IEC 11801 |
| Installation Temperature | -20 to 60°C (-4 to 140°F) |
| Ambient Storage Temperature | -20 to 75°C (-4 to 167°F) |
| Ambient Operating Temperature | -20 to 60°C (-4 to 140°F) |
| Pack Option | Single Unit; 10-Pack; 24-Pack |
Frequently Asked Questions
What is the length of the UACC-CABLE-PATCH-EL-C6A-3M-W?
The cable is 3 m (9.8 ft) long from end to end.
What Ethernet speed does this cable support?
Ubiquiti specifies a supported data rate of 10 GbE.
What connectors are fitted to the cable?
Both ends use translucent booted shielded RJ45 connectors designed for optimal Etherlighting brightness on compatible equipment.
Does the cable support PoE?
Yes. Ubiquiti specifies support for PoE up to PoE+++.
Is this cable intended for outdoor installation?
No. The exact UACC-CABLE-PATCH-EL-C6A-3M-W is specified for indoor operation. Ubiquiti lists a separate Premium Patch Cable Outdoor range for outdoor installations.
What is the minimum bend radius?
The specified minimum bend radius for the 3 m version is 24 mm.
