Eaton N002-002-BK Tripp Lite 2 ft Cat5e Ethernet Cable Black RJ45 M M
The Eaton Tripp Lite N002-002-BK is a 2 ft (0.61 m) Cat5e Ethernet patch cable designed for short network connections. It features black PVC construction, four-pair stranded copper UTP, and molded RJ45 male connectors with integral strain relief.
Cat5e Gigabit Ethernet Connectivity
The N002-002-BK is rated for 350 MHz and 1 Gbps communications. It supports 1000Base-T Gigabit Ethernet as well as 10/100Base-T Ethernet and other compatible Category 5/5e networking applications.
Molded RJ45 Connectors
Both ends use standard RJ45 male connectors with molded construction and integral strain relief. Gold-plated contacts provide the connector interface used for Ethernet networking connections.
UTP Copper Construction
The cable uses 26 AWG, four-pair stranded copper conductors with unshielded twisted-pair construction and a PVC jacket. The 2 ft length is intended for short patch connections between compatible RJ45 network ports.
PoE+ Support
The N002-002-BK supports Type 2 PoE+ under IEEE 802.3at for compatible network equipment and installations.
Key Features
- 2 ft (0.61 m) Cat5e Ethernet patch cable
- RJ45 male-to-male molded connectors with integral strain relief
- 350 MHz maximum tested bandwidth and up to 1 Gbps network speed
- 26 AWG, four-pair stranded copper UTP construction
- Type 2 PoE+ support under IEEE 802.3at
Applications
The N002-002-BK is suitable for short Ethernet connections between switches, routers, patch panels, computers, servers, network appliances, and other RJ45-equipped equipment. Its compact length can help reduce excess cable in rack and workstation installations.
Specifications
| Specification | Details |
|---|
| Brand | Eaton Tripp Lite |
| Part Number / MPN | N002-002-BK |
| Product Type | Cat5e Ethernet Patch Cable |
| Cable Length | 2 ft (0.61 m) |
| Cable Category | Cat5e |
| Connector Type | RJ45 Male to RJ45 Male |
| Connector Plating | Gold |
| Cable Construction | 4-pair stranded UTP |
| Conductor Material | Stranded Copper |
| Conductor Gauge | 26 AWG |
| Cable Shielding | UTP / Unshielded |
| Cable Jacket Material | PVC |
| Cable Jacket Rating | CM |
| Cable Color | Black |
| Network Speed | 1 Gbps (Gigabit) |
| Bandwidth per TIA Standard | 100 MHz |
| Maximum Tested Bandwidth | 350 MHz |
| PoE Support | Type 2 PoE+ (IEEE 802.3at) |
| IEEE Standard | IEEE 802.3ab |
| Outer Cable Diameter | 5.0 mm |
| Number of Conductors | 4 Pair |
| Operating Temperature | 14° to 104°F (-10° to 40°C) |
| Operating Humidity | 0% to 90% RH, non-condensing |
| Storage Temperature | 5° to 122°F (-15° to 50°C) |
| Storage Humidity | 0% to 90% RH, non-condensing |
| Compliance | RoHS, REACH |
| Certifications | UL Listed, cUL Listed |
| Warranty | Lifetime limited warranty |
| UPC | 037332141156 |
Package Contents
- 1 × N002-002-BK 2 ft Black Cat5e Molded Patch Cable
Frequently Asked Questions
What category is the N002-002-BK?
The N002-002-BK is a Cat5e Ethernet patch cable rated for 350 MHz and 1 Gbps communications.
What connectors are used?
The cable has RJ45 male connectors on both ends.
Is the N002-002-BK shielded?
No. It uses unshielded twisted-pair (UTP) construction.
Does it support PoE+?
Yes. Eaton specifies Type 2 PoE+ support under IEEE 802.3at.
How long is the cable?
The N002-002-BK is 2 ft (0.61 m) long.
What conductor size does it use?
The cable uses 26 AWG stranded copper conductors in a four-pair UTP configuration.
