Ergotron 24-191-085 – Neo-Flex Mobile MediaCenter VHD, Black
Overview
The Ergotron 24-191-085 Neo-Flex Mobile MediaCenter VHD is a very heavy-duty mobile display cart designed for moving and positioning large displays throughout professional environments. Its Constant Force height adjustment, integrated display rotation and mobile base support flexible presentation, digital signage, conferencing and collaboration deployments.
Technical Information
The VHD configuration supports displays weighing 50–90 lb (22.7–40.8 kg). It provides 20 inches (51 cm) of height adjustment, 20° of independent display tilt and 90° portrait-to-landscape rotation. The display mount supports VESA MIS-D/F mounting patterns, with the exact compatible hole pattern determined by the display weight and mounting configuration.
Compatibility
The 24-191-085 is intended for large displays in the 37–75 inch range. Ergotron notes that screen size is an approximation and that displays outside the typical size range may be used when the display remains within the specified weight and mounting limits. Supported mounting dimensions include horizontal patterns of 200, 300, 400, 500 and 600 mm and vertical measurements of 200 mm or 225–400 mm. An optional 97-489 800 mm Accessory Kit can expand the horizontal mounting capability to 660 or 800 mm.
Key Features
- Supports displays weighing 50–90 lb (22.7–40.8 kg).
- Provides 20 inches (51 cm) of effortless height adjustment.
- Offers 20° independent display tilt and 90° portrait-to-landscape rotation.
- Supports large-format VESA MIS-D/F display mounting patterns.
- Includes a rugged lower main shelf, rear cable shelf and modular cable-management channel system.
Applications
The Neo-Flex Mobile MediaCenter VHD is suited to conference rooms, presentation spaces, training facilities, classrooms, digital-signage deployments, healthcare environments and other locations where large displays need to be repositioned between rooms or work areas.
DC Supplies Product Note
For deployment, verify the display's actual weight and VESA mounting dimensions rather than relying only on screen diagonal. The VHD display capacity is 50–90 lb, while the main shelf is rated for 30 lb and the rear cable shelf for 5 lb. Adding certain optional accessories can reduce the available display capacity, so the final configuration should be checked before installation.
Specifications
| Brand | Ergotron |
|---|
| MPN | 24-191-085 |
|---|
| Product Type | Mobile Display Cart |
|---|
| Series | Neo-Flex Mobile MediaCenter |
|---|
| Model | VHD – Very Heavy Duty |
|---|
| Finish | Black |
|---|
| Typical Display Size | 37–75 in |
|---|
| Display Capacity | 50–90 lb (22.7–40.8 kg) |
|---|
| Height Adjustment | 20 in (51 cm) |
|---|
| Display Tilt | 20° |
|---|
| Display Rotation | 90° portrait-to-landscape |
|---|
| VESA Standard | MIS-D/F |
|---|
| Horizontal Mounting Patterns | 200, 300, 400, 500 and 600 mm |
|---|
| Vertical Mounting Patterns | 200 mm or 225–400 mm |
|---|
| Main Shelf Capacity | 30 lb (13.6 kg) |
|---|
| Cable Shelf Capacity | 5 lb (2.2 kg) |
|---|
| Casters | 4-inch (100 mm) casters; two locking |
|---|
| Cable Management | Rear cable shelf and modular cable channel system |
|---|
| CPU Compatibility | 12 in H × 3 in D to 18 in H × 8.5 in D |
|---|
| Shipping Dimensions | 66 × 20 × 14 in (1680 × 503 × 335 mm) |
|---|
| Shipping Weight | 101 lb (46 kg) |
|---|
| Warranty | 3 years |
|---|
FAQs
What is the Ergotron 24-191-085?
It is the Neo-Flex Mobile MediaCenter VHD, a very heavy-duty mobile cart for large displays.
What display weight does the VHD support?
The display capacity is 50–90 lb (22.7–40.8 kg).
What display size is supported?
The typical specified range is 37–75 inches. Ergotron states that screen size is approximate and that weight and VESA compatibility are the determining factors.
How much height adjustment does the cart provide?
The display assembly provides 20 inches (51 cm) of height adjustment.
Can the display be used in portrait orientation?
Yes. The display assembly provides 90° rotation for portrait-to-landscape positioning. Ergotron notes that portrait orientation may not be recommended for some plasma displays.
What VESA mounting patterns are supported?
The VHD uses VESA MIS-D/F mounting. Supported horizontal measurements include 200, 300, 400, 500 and 600 mm, with vertical measurements of 200 mm or 225–400 mm.
What is the main shelf capacity?
The lower main shelf is rated for 30 lb (13.6 kg). The rear cable shelf is rated for 5 lb (2.2 kg).
Is the cart powered?
The display height adjustment is mechanical and uses Ergotron's Constant Force technology; no powered lift is specified for this model.
What accessories are available?
Compatible options include the 97-491-085 MMC Camera Shelf Kit, 97-489 800 mm Accessory Kit and 97-527-009 VESA CPU Mount. These accessories are ordered separately.
What is the warranty?
Ergotron specifies a 3-year warranty for the Neo-Flex Mobile MediaCenter VHD.
