Ergotron 45-246-026 – LX Wall Mount Keyboard Arm, Polished Aluminum
Overview
The Ergotron 45-246-026 LX Wall Mount Keyboard Arm is an adjustable keyboard mounting solution for ergonomic workstation configurations. The polished aluminum arm provides up to 13 inches of vertical adjustment and extends the keyboard tray up to 35 inches from the wall, allowing users to position the keyboard for comfortable seated or standing operation.
Technical Information
The LX Wall Mount Keyboard Arm supports keyboards and associated input devices up to 5 lb. Its Constant Force technology enables smooth positioning with light touch, while the keyboard tray provides a 5-degree back tilt in the operating position. The arm can pan through 360 degrees and folds to approximately 3.5 inches from the wall when stored.
Compatibility
The 45-246-026 mounts directly to sturdy vertical surfaces, including suitable wood-stud or concrete wall installations using the supplied mounting hardware. It can also be attached to an Ergotron Wall Track using bracket 97-091, which is sold separately. For steel-stud wall installations, Ergotron recommends the Steel Stud Wall Mounting Kit 60-591-003.
Key Features
- Supports keyboard loads up to 5 lb (2.3 kg)
- Provides 13 inches of vertical lift and up to 35 inches of extension
- 360-degree pan for flexible keyboard positioning
- Ergonomic back-tilt keyboard tray with integrated mouse tray and wrist rest
- Folds to approximately 3.5 inches from the wall when not in use
Applications
The 45-246-026 is suited to space-constrained workstations, healthcare environments, office workstations, industrial data-entry areas and other applications requiring an adjustable wall-mounted keyboard platform. It can be paired with an Ergotron LX monitor arm to create a complete wall-mounted workstation.
DC Supplies Product Note
DC Supplies recommends verifying the exact manufacturer part number before ordering. The 45-246-026 is the standard LX Wall Mount Keyboard Arm in polished aluminum. It should not be confused with the LX Sit-Stand Wall Mount Keyboard Arm, which uses a different part number.
Specifications
| Brand | Ergotron |
|---|
| Manufacturer Part Number | 45-246-026 |
|---|
| Product | LX Wall Mount Keyboard Arm |
|---|
| Product Type | Wall-mounted keyboard arm |
|---|
| Color | Polished aluminum |
|---|
| Maximum Load Capacity | 5 lb (2.3 kg) |
|---|
| Lift | 13 in (33 cm) |
|---|
| Extension From Wall | Up to 35 in (89 cm) |
|---|
| Pan | 360° |
|---|
| Keyboard Tray Size | 17.5 x 10.1 in (44.5 x 25.7 cm) |
|---|
| Operating Tray Tilt | 5° back tilt |
|---|
| Storage Position | Folds to approximately 3.5 in (9 cm) from wall |
|---|
| Mounting | Direct to sturdy vertical surfaces; Wall Track with 97-091 bracket |
|---|
| Construction | Aluminum |
|---|
| Product Weight | 9.2 lb |
|---|
| Shipping Weight | 11.6 lb |
|---|
| Shipping Dimensions | 20.0 x 11.9 x 5.5 in (51 x 30 x 14 cm) |
|---|
| Warranty | 10 years |
|---|
FAQs
What is the Ergotron 45-246-026?
The 45-246-026 is the Ergotron LX Wall Mount Keyboard Arm in polished aluminum, designed to provide adjustable wall-mounted keyboard positioning.
What is the maximum load capacity?
The maximum specified load capacity is 5 lb (2.3 kg).
How far does the keyboard arm extend?
The arm extends the keyboard tray up to 35 inches (89 cm) from the wall.
How much vertical adjustment does it provide?
The LX Wall Mount Keyboard Arm provides 13 inches (33 cm) of vertical lift.
Does the keyboard tray tilt?
Yes. The tray provides a 5-degree back tilt in the operating position. It can also fold upright 90 degrees for storage.
How far does it fold toward the wall?
When stored, the arm folds to approximately 3.5 inches (9 cm) from the wall.
Can the arm be installed on an Ergotron Wall Track?
Yes. The arm can attach to an Ergotron Wall Track using bracket 97-091, which is sold separately.
What is included?
The package includes the LX arm, extension, keyboard tray, mouse tray, wall mount base, mouse holder, wrist rest and mounting fasteners for applicable wood-stud or concrete wall installations.
What warranty does Ergotron provide?
Ergotron specifies a 10-year warranty for the 45-246-026 LX Wall Mount Keyboard Arm.
