Ergotron 45-230-200 – 200 Series Combo Arm, Black
Overview
The Ergotron 45-230-200 is a black 200 Series Combo Arm designed to combine a monitor and keyboard into a wall-mounted workstation. The system provides an adjustable LCD mount, integrated keyboard tray, mouse and barcode scanner holder, wrist rest and concealed cable management.
Its three-point telescoping arm allows the keyboard and display assembly to extend toward the user and fold back when the workstation is not required. Ergotron Constant Force technology provides fluid, one-touch adjustment of the LCD height.
Technical Information
The 45-230-200 supports a typical display size of up to 24 inches with a display capacity of 6–18 lb (2.7–8.2 kg). The LCD provides 5 inches (13 cm) of vertical adjustment, while the keyboard tray remains at a fixed height.
The monitor provides 30° tilt, 360° pan and 360° rotation. The integrated keyboard, mouse and barcode scanner have a separate combined capacity of 5 lb (2.3 kg). The keyboard tray incorporates a negative-tilt design and a mouse tray that can be positioned on either side.
Compatibility
The 45-230-200 supports VESA FDMI MIS-D mounting with 75 x 75 mm and 100 x 100 mm hole patterns. Ergotron identifies displays up to 24 inches as the typical size; display weight must remain within the 6–18 lb rated capacity.
The arm mounts to sturdy vertical surfaces and can be attached directly to suitable wood-stud or concrete wall structures using the supplied mounting hardware. For steel-stud installations, Ergotron recommends its Steel Stud Wall Mounting Kit 60-591-003. A Wall Plate or Wall Track can be used where additional wall support is required.
Key Features
- Exact Ergotron part number 45-230-200 in black
- Wall-mounted 200 Series Combo Arm for monitor and keyboard
- 5-inch (13 cm) LCD height adjustment using Constant Force technology
- 6–18 lb (2.7–8.2 kg) display capacity with VESA MIS-D mounting
- Integrated keyboard, mouse, barcode scanner, wrist-rest and concealed cable-management features
Applications
The Ergotron 45-230-200 is suited to healthcare workstations, clinical environments, laboratories, registration stations, industrial work areas and other space-constrained installations requiring a wall-mounted monitor and keyboard workstation.
DC Supplies Product Note
The 45-230-200 is specifically the black configuration of the Ergotron 200 Series Combo Arm. The closely related 45-230-216 is the white version. Verify the exact MPN, display weight, VESA pattern and wall construction before deployment.
Specifications
| Specification | Details |
|---|
| Brand | Ergotron |
| Part Number | 45-230-200 |
| Product | 200 Series Combo Arm |
| Color | Black |
| Mounting Type | Wall mount |
| Typical Display Size | Up to 24 in |
| Display Capacity | 6–18 lb (2.7–8.2 kg) |
| Keyboard/Mouse/Scanner Capacity | 5 lb (2.3 kg) |
| Display Height Adjustment | 5 in (13 cm) |
| Monitor Tilt | 30° |
| Monitor Pan | 360° |
| Monitor Rotation | 360° |
| VESA Standard | VESA FDMI MIS-D |
| VESA Mounting Patterns | 75 x 75 mm and 100 x 100 mm |
| Keyboard Tray | Integrated tray with left/right mouse tray |
| Keyboard Tray Tilt | Negative tilt; 10° back / 0° forward |
| Scanner Holder | Integrated |
| Cable Management | Concealed cable routing |
| Construction | Aluminum, high-grade plastic and powder-coated steel |
| Product Weight | 18.1 lb (8.2 kg) |
| Shipping Dimensions | 12.4 x 20 x 23.6 in (315 x 508 x 605 mm) |
| Shipping Weight | 25.9 lb (11.8 kg) |
| Warranty | 5 years |
FAQs
What is the Ergotron 45-230-200?
The 45-230-200 is Ergotron's black 200 Series Combo Arm, a wall-mounted workstation for a monitor, keyboard, mouse and barcode scanner.
What monitor size does the 45-230-200 support?
Ergotron specifies a typical display size of up to 24 inches. The display must remain within the 6–18 lb (2.7–8.2 kg) capacity range.
What is the monitor weight capacity?
The LCD mount supports 6–18 lb (2.7–8.2 kg). The keyboard, mouse and barcode scanner have a separate combined capacity of 5 lb (2.3 kg).
How much height adjustment does the monitor have?
The LCD provides 5 inches (13 cm) of height adjustment. The keyboard tray height is fixed.
What VESA patterns are supported?
The 45-230-200 uses VESA FDMI MIS-D and supports 75 x 75 mm and 100 x 100 mm mounting patterns.
Does it include a keyboard tray?
Yes. The system includes an integrated keyboard tray with left/right mouse tray, wrist rest, scanner and mouse holder, handle, VESA mounting kit and cable ties.
Can the monitor rotate?
Yes. The display provides 360° rotation and 360° pan, together with 30° tilt.
What is the difference between 45-230-200 and 45-230-216?
Both are 200 Series Combo Arms with the same general configuration. The 45-230-200 is the black version, while 45-230-216 is the white version.
Can the 45-230-200 be installed on a steel-stud wall?
Ergotron states that fasteners for direct attachment to metal studs are not included and recommends Steel Stud Wall Mounting Kit 60-591-003 when the wall is supported with steel studs.
