Ergotron 45-270-026 – StyleView Sit-Stand Combo System with Worksurface
Overview
The Ergotron 45-270-026 is a StyleView Sit-Stand Combo System with an integrated worksurface and medium CPU holder. The wall-mounted workstation combines a height-adjustable LCD arm, keyboard tray, wrist rest, scanner and mouse holders, cable management, and a 34-inch Wall Track system for clinical and professional computing environments.
Technical Information
The system provides 20 inches (51 cm) of single-motion LCD and keyboard adjustment, plus 5 inches (13 cm) of independent LCD height adjustment, for a maximum LCD height adjustment of 25 inches (64 cm). The LCD mount provides 30° tilt, 360° pan, and 90° rotation. The system supports displays up to 24 inches and a total equipment capacity of up to 32 lb (14.5 kg).
Compatibility
The 45-270-026 supports one VESA MIS-D display using 75 x 75 mm or 100 x 100 mm mounting patterns. The included medium CPU holder supports a CPU up to 50 lb (22.7 kg). The Wall Track and mounting hardware support installation on suitable concrete or wood surfaces. The optional 45-261-026 extender arm can extend the system's reach when required.
Key Features
- StyleView wall-mounted sit-stand workstation with integrated worksurface
- 25-inch (64 cm) maximum LCD height adjustment
- Supports displays up to 24 inches with VESA MIS-D mounting
- Medium CPU holder supports up to 50 lb (22.7 kg)
- Includes 34-inch Wall Track, keyboard tray, wrist rest, scanner and mouse holders, and cable-management components
Applications
The StyleView Sit-Stand Combo System is designed for healthcare and professional computing environments where monitor, keyboard, scanner, mouse, and computer equipment need to remain organized while allowing users to work in seated or standing positions. Its wall-mounted architecture helps keep the workstation footprint clear.
DC Supplies Product Note
Confirm the mounting surface and display/CPU dimensions before installation. The 45-270-026 specifically includes the worksurface and medium CPU holder; the closely related 45-272-026 uses a small CPU holder and should not be substituted when the medium holder configuration is required.
Specifications
| Specification | Details |
|---|
| Brand | Ergotron |
| Part Number / MPN | 45-270-026 |
| Product Type | Wall-Mounted Sit-Stand Workstation |
| Product Series | StyleView Sit-Stand Combo System |
| Finish | Polished Aluminum |
| Monitor Configuration | Single Monitor |
| Maximum Display Size | 24 inches |
| Maximum System Capacity | 32 lb (14.5 kg) |
| CPU Holder Capacity | 50 lb (22.7 kg) |
| LCD and Keyboard Lift | 20 inches (51 cm) |
| Independent LCD Adjustment | 5 inches (13 cm) |
| Maximum LCD Height Adjustment | 25 inches (64 cm) |
| LCD Tilt | 30° (+25° / -5°) |
| LCD Pan | 360° |
| LCD Rotation | 90° |
| VESA Mounting | MIS-D, 75 x 75 mm and 100 x 100 mm |
| Worksurface | 22.75 x 10.6 inches (57.8 x 26.9 cm) |
| Wall Track | 34 inches |
| Mounting Type | Wall Mount |
| Maximum Extension | 43 inches (109 cm); up to 60 inches (152 cm) with extender |
| Folded Depth | 8 inches (20.3 cm) |
| Warranty | 5 years |
FAQs
What is the Ergotron 45-270-026?
It is a StyleView Sit-Stand Combo System with an integrated worksurface, medium CPU holder, wall track, and adjustable LCD mounting system.
How much height adjustment does it provide?
The LCD and keyboard adjust together through 20 inches (51 cm), with an additional 5 inches (13 cm) of independent LCD adjustment, providing up to 25 inches (64 cm) of LCD height adjustment.
What size monitor does it support?
The system supports a display up to 24 inches, using VESA MIS-D mounting patterns.
What CPU capacity does the included holder provide?
The medium CPU holder included with the 45-270-026 supports up to 50 lb (22.7 kg).
What is included with the 45-270-026?
The system includes the StyleView Sit-Stand Combo Arm with worksurface, 34-inch Wall Track with covers, medium CPU holder, CPU spacer, cable channels, CPU and arm track-mount bracket kits, wall-mount hardware for concrete and wood, direct CPU wall-mount kit, height-adjustable LCD mount, wrist rest, scanner and mouse holders, integrated keyboard tray, VESA monitor mounting kit, and cable ties.
