Overview
The Ubiquiti UACC-AOC-QSFP28-10M is a 10-meter 100G Long-Range Direct Attach Cable designed for high-bandwidth connections between compatible QSFP28 or QSFP+ interfaces. It uses OM3 fiber with an 850nm wavelength and QSFP28 connectors at both ends.
Optical Connectivity
The cable supports data rates up to 100 Gbps and is compatible with QSFP28 and QSFP+ interfaces. Its OM3 fiber construction and 850nm wavelength provide a defined optical platform for high-speed network interconnects.
Physical Construction
The 10-meter cable has an aqua PVC jacket with a 3.0 mm outer diameter. A minimum bend radius of 30 mm helps define the cable's installation requirements, while the 0 to 70°C operating range supports standard data-center and network equipment environments.
Key Features
- 100 Gbps maximum supported data rate
- 10-meter length for longer rack-to-rack or equipment interconnections
- QSFP28-to-QSFP28 connector configuration
- OM3 fiber with 850 nm wavelength
- 30 mm minimum bend radius with aqua PVC jacket
Applications
The UACC-AOC-QSFP28-10M is suited to high-speed network interconnections where compatible QSFP28 or QSFP+ ports require a 10-meter optical cable assembly. It can be used for equipment-to-equipment connectivity in data-center and high-bandwidth networking environments.
DC Supplies Product Note
At 10 meters, this version provides substantially more reach than short passive direct-attach assemblies, making cable-path planning important when connecting equipment across racks or network cabinets.
Specifications
| Brand | Ubiquiti |
|---|
| Part Number / MPN | UACC-AOC-QSFP28-10M |
|---|
| Product Type | 100G Long-Range Direct Attach Cable |
|---|
| Cable Length | 10 m (32.8 ft) |
|---|
| Maximum Data Rate | 100 Gbps |
|---|
| Supported Data Rates | 100 / 40 Gbps |
|---|
| Connector Type | QSFP28 to QSFP28 |
|---|
| Interface Compatibility | QSFP28 and QSFP+ |
|---|
| Fiber Type | OM3 |
|---|
| Wavelength | 850 nm |
|---|
| Jacket Color | Aqua |
|---|
| Jacket Material | PVC |
|---|
| Jacket Outer Diameter | 3.0 mm |
|---|
| Minimum Bend Radius | 30 mm |
|---|
| Maximum Power Consumption | 3.5 W |
|---|
| Operating Temperature | 0 to 70°C (32 to 158°F) |
|---|
| Pack Option | Single Unit |
|---|
FAQs
What is the length of the UACC-AOC-QSFP28-10M?
The cable is 10 meters (32.8 feet) long.
What data rate does this cable support?
The cable supports a maximum data rate of 100 Gbps, with 100 Gbps and 40 Gbps listed as supported rates.
What connectors are used?
It has QSFP28 connectors on both ends.
Is the cable compatible with QSFP+ interfaces?
Yes. Ubiquiti specifies compatibility with both QSFP28 and QSFP+ interfaces.
