Detailed Specifications
NVIDIA 980-9IAM3-00X02A 1 6Tbps OSFP ACC Cable
Overview :
The NVIDIA 980-9IAM3-00X02A is a 1.6Tbps OSFP active copper cable designed for high-density InfiniBand and Ethernet fabrics used in AI and HPC clusters. It provides direct-attach copper connectivity with integrated signal conditioning to maintain signal integrity at extreme data rates. This cable supports short-reach interconnects between switches and servers in rack-scale deployments. It is commonly deployed in NVIDIA Quantum-X800 environments where ultra-low latency and high bandwidth are required.
Key Features :
1.6Tbps aggregate bandwidth support
OSFP224 active copper twinax design
Optimized for XDR InfiniBand fabrics
Low-latency short-reach connectivity
Technical Specifications :
| Specification | Details |
|---|
| Brand | NVIDIA |
| Part Number | 980-9IAM3-00X02A |
| Product Type | Active Direct Attach Copper Cable |
| Cable Type | OSFP Active Copper Cable (ACC) |
| Aggregate Data Rate | 1600 Gbps |
| Per Port Throughput | 2 × 800 Gbps |
| Connector Type | OSFP224 |
| Cable Length | 2.5 m |
| Signaling | PAM4 modulation |
| Typical Latency | ~75-85 ns |
| Power Consumption | Up to 2.5 W per end |
| Minimum Bend Radius | 90 mm |
| Supported Protocols | InfiniBand XDR, Ethernet |
| Conductor Gauge | 26 AWG twinax |
