Detailed Specifications
ACDC2405 - Thermal Containment Door Post (1200-1500 mm Aisle)
Overview
The APC ACDC2405 is a vertical door post used in APC NetShelter aisle-containment systems. It's engineered to support containment doors for aisles that are 1200 to 1500 mm (48-60 in) wide × a common aisle width in many data centre rows. By installing this post, you help ensure structural integrity for the containment assembly while maintaining a thermal barrier between hot and cold aisles. This component is particularly relevant when building scalable row-level containment: it's one of the "legs" that holds up the door frame, making the entire containment system modular yet robust.
Key Features
Supports aisle containment doors in 1200-1500 mm (48-60 in) wide aisles.
Strong steel construction ensures stable mounting and long-term durability.
Powder-coated black finish aligns with standard NetShelter enclosures.
Environmentally compliant with RoHS and REACH standards.
Pre-configured lower brackets make installation on SX or VX enclosures straightforward.
Technical Specifications
| Specification | Detail |
|---|
| Brand | APC by Schneider Electric |
| Part Number | ACDC2405 |
| Product Type | Thermal Containment Door Post |
| Aisle Width Supported | 1200-1500 mm (48-60 in) |
| Height | ~318 mm (12.5 in) |
| Width | ~479 mm (18.9 in) |
| Depth | ~2481 mm (97.7 in) |
| Weight | ~27.5 kg (60.6 lb) |
| Material / Finish | Steel, black powder-coat |
| Environmental Compliance | RoHS, REACH |
