Detailed Specifications
Eaton B064-000-STN - KVM Over IP Remote Console Station
Overview
The Eaton B064-000-STN is a KVM over IP remote-user console station designed for IT infrastructure environments that deploy Eaton/Tripp Lite B064-IPG series KVM over IP switches. It provides a dedicated user interface for keyboard, video, and mouse access to remote KVM switches without requiring a PC or workstation at the console location. This simplifies secure remote access and eliminates issues associated with general-purpose computers in control stations (OS patching, malware exposure).
This station supports a single KVM switch connection and provides HDMI video up to 1920 × 1200 @ 60 Hz, four USB ports (keyboard/mouse/peripherals), and Gigabit Ethernet network connectivity. The unit runs from an external 100 - 240 VAC power supply and is qualified for typical server room and rack environments.
B064-000-STN fits into rack environments via its desktop form factor with optional rear-rack (0U) mount plate, or it can sit on a flat surface with rubber feet included. It is deployed at IDF/Server Rooms, data center racks, and network closets alongside B064-IPG KVM switches to provide local user console access.
The console integrates with Eaton/Tripp Lite IP-enabled KVM switches and supports features such as virtual media for remote USB storage redirection. It operates from a Java-free platform, removing dependencies on general-purpose OS environments and reducing maintenance overhead at console stations.
In practical terms, this device is used where operators require direct visual and control access to servers via a single console without a PC in the workspace × for example in data center NOC stations or consolidation racks. It is not a standalone KVM switch and does not connect directly to servers without a compatible B064-IPG KVM switch.
Avoid using B064-000-STN for multi-user console switching beyond its intended single-switch scope or in environments requiring higher-resolution video beyond 1920 × 1200 without external scaling/conversion.
Key Features
- Remote IP console station for single B064-IPG KVM switch
- HDMI video up to 1920 × 1200 @ 60 Hz resolution
- Four USB 2.0 console ports for keyboard/mouse/peripherals
- Gigabit Ethernet for IP connectivity and control
- Desktop + optional 0U rack mounting configuration
Specifications
| Specification | Value |
|---|
| Brand | Eaton |
| Part Number | B064-000-STN |
| Product Type | KVM over IP Remote-User Console Station |
| Video Output | 1 × HDMI Type A, up to 1920 × 1200 @ 60 Hz |
| USB Ports | 4 × USB 2.0 (keyboard/mouse/peripherals) |
| Network Interface | 1 × RJ45 Gigabit Ethernet |
| Power Input | External PSU 100 - 240 VAC, 50/60 Hz |
| Power Consumption | ~4.66 W |
| HDCP | Version 1.4 |
| Dimensions (HxWxD) | ~28.7 × 149.4 × 174.2 mm (1.13″ × 5.88″ × 6.86″) |
| Weight | ~1.65 lb (~0.75 kg) |
| Mounting | Desktop, optional 0U rear-rack plate |
| Operating Temp. | 0 °C to 40 °C |
| Storage Temp. | -20 °C to 60 °C |
| Operating Humidity | 0 % to 80 % RH (non-condensing) |
| Compliance | FCC, CE, RoHS, REACH; TAA compliant |
| Warranty | Manufacturer limited |
