Detailed Specifications
ACER ZF.P01AA.01K Chromebook Enterprise Tab 510 D652N-S1ML-CE-US
Overview :
The Acer ZF.P01AA.01K (Model D652N-S1ML-CE-US) is a commercial-grade 10.1-inch touchscreen ChromeOS tablet engineered for modern mobile enterprise workforces, frontline service industries, health diagnostics, and decentralized educational management networks. It overcomes traditional handheld vulnerability risks by reinforcing an ultra-portable tablet form factor with certified MIL-STD 810H military-grade impact resistance and an unlocked Chrome Enterprise Upgrade license for remote zero-trust asset administration.
This specialized tablet is powered by the Qualcomm Snapdragon 7c Gen 2 Compute Platform, integrating a power-efficient Kryo 468 octa-core processing architecture with an Adreno 618 graphics engine. The system includes 4 GB of integrated LPDDR4X memory and 64 GB of fast onboard storage. The physical configuration features a 10.1-inch WUXGA (1920 x 1200) 16:10 multi-touch IPS display shielded with Antimicrobial Corning Gorilla Glass, a dual-camera array consisting of a 5 MP front camera and an 8 MP world-facing camera, dual user-facing speakers, and a fast-charging dockable USI stylus.
Deployment environments focus on logistics yards, clinical registration desks, field inspection paths, hospitality hubs, and roving administrative operations. The integrated Chrome Enterprise platform bypasses localized data leaks by enforcing hardware-level token encryptions while enabling automated, out-of-the-box Zero-Touch Enrollment directly into corporate cloud security pools via the central Google Admin Console.
The tablet delivers fluent real-time operations for enterprise SaaS web entry platforms, interactive inventory sheets, Google Workspace applications, and secure virtual desktop pipelines using localized VDI clients. It is not suitable for complex development paths demanding bare-metal local execution layers for legacy Windows binaries (.exe installations) or heavy, continuous offline 3D design tasks that lack cloud-hosted computing nodes.
Key Features :
Qualcomm Snapdragon 7c Gen 2 SoC balances responsive web tasks with a 10-hour battery runtime.
10.1-inch WUXGA 16:10 multi-touch display provides exceptionally crisp text and image outputs.
Antimicrobial Corning Gorilla Glass surface structure guards the touchscreen against stain and odor bacteria.
Dockable USI active pen charges inside the tablet chassis to enable immediate on-screen inputs and signatures.
MIL-STD 810H compliant body with shock-absorbent corner bumpers defends against drops up to 122 cm.
Specifications :
| Attribute | Specification |
| Brand | ACER |
| Part Number | ZF.P01AA.01K |
| Product Type | ChromeOS Tablet |
| Product Line | Chromebook Enterprise Tab 510 |
| Product Series | D652N Series |
| Product Model | D652N-S1ML-CE-US |
| Processor | Qualcomm Snapdragon 7c Gen 2 Compute Platform (Kryo 468 Octa-Core, up to 2.55 GHz) |
| System Memory | 4 GB LPDDR4X SDRAM (Onboard Configuration) |
| Storage Capacity | 64 GB eMMC Onboard Flash Storage |
| Operating System | ChromeOS (with Chrome Enterprise Upgrade License Unlocked) |
| Display Resolution | 10.1" WUXGA (1920 x 1200), 60 Hz, 16:10 Aspect Ratio |
| Display Technology | Active Matrix TFT LCD In-plane Switching (IPS) Touchscreen |
| Glass Technology | Antimicrobial Corning Gorilla Glass Protection |
| Graphics Controller | Qualcomm Adreno 618 Graphics (Shared System Memory Access) |
| USB Interfaces | 1 x USB 3.2 Gen 1 Type-C Port (Supports DC-In, Power Delivery, and DisplayPort Alt Mode) |
| Audio Components | 2 x Integrated Front-Facing Speakers, Dual Microphones, 3.5mm Combo Jack |
| Wireless Architecture | Wi-Fi 5 (IEEE 802.11a/b/g/n/ac) + Bluetooth 5.0 Wireless |
| Input Accessories | Multi-touch Screen, Integrated Dockable USI Stylus Pen (4096 Pressure Levels) |
| Camera System | 5 Megapixel Front-Facing Webcam, 8 Megapixel Rear World-Facing Camera |
| Security Hardware | Google Security H1 Chip Layer, Kensington Security Slot |
| Power Profile | 45 W Type-C AC Adapter (Long-Life Lithium Ion Battery) |
| Environmental Certification | ENERGY STAR Certified, EPEAT Compliant |
