Detailed Specifications
Ubiquiti UACC-CAMERA-DM-B Dual Camera Mount
Overview
The Ubiquiti UACC-CAMERA-DM-B is a tamper-resistant dual-mount bracket for UniFi Protect cameras, designed to hold two cameras back-to-back on a single support. It supports surface, pole, and pendant mounting with a 1 1/2″ NPS threaded conduit interface included for professional installs. Compatibility spans a wide range of UniFi camera models, including G3-Pro, G4, G5, and AI series variants for flexible deployment. This bracket is suitable for commercial and enterprise surveillance where paired viewpoints or symmetrical coverage are required.
Key Features
• Dual back-to-back camera mount
• Includes 1 1/2″ NPS threaded conduit
• Surface, pole & pendant mounting
• Compatible with many UniFi Protect cameras
Technical Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number | UACC-CAMERA-DM-B |
| Product Type | Dual Camera Mount Bracket |
| Mounting Options | Surface, pole, pendant |
| Threaded Interface | 1 1/2″ NPS conduit |
| Compatibility | UniFi Protect cameras: UVC-G3-Pro, UVC-G4-Pro, UVC-G5-Pro, UVC-G3-Bullet, UVC-G4-Bullet, UVC-G5-Bullet, UVC-AI-Bullet, UVC-AI-DSLR, UVC-AI-Pro, UVC-AI-Turret, UVC-AI-Dome, UVC-G5-Turret-Ultra, UVC-G5-Dome-Ultra |
| Enclosure Materials | Aluminum alloy, polycarbonate |
| Mounting Material | Aluminum alloy |
| Pole Mount Diameter | 1.5″-2″ (metal strap torque: 6 Nm) |
| Dimensions | 260 × 118 × 103 mm |
| Weight | 920 g |
