Detailed Specifications
Teltonika PR1KS210 Outdoor Multi Band Antenna
Overview :
The Teltonika PR1KS210 is an outdoor multi-band omni-directional antenna supporting cellular, dual-band Wi-Fi, and GNSS positioning. It consolidates multiple radio paths into a single rugged housing for simplified installation and enhanced signal reception. Its IP67-rated design and mounting hardware enable deployments on poles, masts, and exterior walls. The antenna is suited for industrial, transport, and edge networking applications requiring consolidated wireless coverage and positioning support.
Key Features :
Multi-band cellular support
Dual-band Wi-Fi reception
Integrated GNSS gain element
IP67 outdoor enclosure
Technical Specifications :
| Specification | Detail |
|---|
| Brand | Teltonika |
| Part Number | PR1KS210 |
| Product Type | Outdoor Multi-Band Antenna |
| Cellular Range | 617-960 MHz, 1700-2700 MHz |
| Cellular Gain | ~5 dBi |
| Wi-Fi Frequencies | 2400-2500 MHz, 4900-5980 MHz |
| Wi-Fi Gain | ~7 dBi |
| GNSS Range | 1559-1609 MHz |
| GNSS Gain | ~28 dBi |
| Impedance | 50 Ω |
| Connector Interfaces | Multi-connector set |
| VSWR | <2.0 |
| Radiation Pattern | Omni-directional |
| Ingress Protection | IP67 |
| Mounting | Mast/Wall/Ceiling |
| Operating Temp. | -40 °C to 75 °C |
