Detailed Specifications
Teltonika PR1KSG30 Outdoor Multi Radio Antenna
Overview :
The Teltonika PR1KSG30 is an outdoor omni-directional antenna designed for consolidated reception of multiple wireless technologies. It supports cellular LTE/5G, dual-band Wi-Fi, and GNSS positioning to improve connectivity and location services in industrial, edge, and infrastructure deployments. The antenna's IP67-rated enclosure and integrated mounting hardware make it suitable for outdoor installations on walls, masts, and rooftops where durable, weather-resistant operation is required. It is commonly used with routers and gateways to extend signal coverage and enhance wireless performance.
Key Features :
Multi-band cellular support for LTE/5G
Dual-band 2.4 GHz and 5 GHz Wi-Fi reception
High-gain GNSS for GPS/GLONASS/BeiDou/Galileo
IP67 outdoor-rated enclosure
Technical Specifications :
| Specification | Detail |
|---|
| Brand | Teltonika |
| Part Number | PR1KSG30 |
| Product Type | Outdoor Multi-Radio Antenna |
| Cellular Frequency Range | 600-960 MHz, 1710-2700 MHz, 3300-3800 MHz |
| Cellular Max Gain | 5 dBi |
| Wi-Fi Frequency Range | 2400-2500 MHz, 4900-5980 MHz |
| Wi-Fi Max Gain | 7 dBi |
| GNSS Frequency Range | 1559-1609 MHz |
| GNSS Polarization | RHCP |
| GNSS Max Gain | 28 dBi |
| Impedance | 50 Ω |
| VSWR | < 2.0 across bands |
| Connectors | 2 × SMA (cellular), 2 × RP-SMA (Wi-Fi), 1 × SMA (GNSS) |
| Cables Included | Multi-lead low-loss cables |
| Radiation Pattern | Omni-directional |
| Ingress Protection | IP67 |
| Operating Temp. | -40 °C to 75 °C |
| Mounting Options | Wall, mast, or rooftop |
| Weight | ~1.6 kg |
