Detailed Specifications
Teltonika PR1US740 4 Way Outdoor Antenna Splitter
Overview :
The Teltonika PR1US740 is an outdoor antenna splitter designed to divide a single RF input into four outputs with minimal signal loss. It enables distribution of cellular or wireless signals from one antenna source to multiple devices or multiple antenna ports on a router or gateway. The unit features N-type connectors and a weather-resistant enclosure suitable for outdoor or exposed installations. It fits multi-antenna network deployments such as cellular, Wi-Fi distribution, and multi-radio system setups where consolidated RF signal routing is required.
Key Features :
1×4 RF signal splitter for outdoor use
N-type connector interfaces
Weather-resistant housing
Low insertion loss design
Technical Specifications :
| Specification | Detail |
|---|
| Brand | Teltonika |
| Part Number | PR1US740 |
| Product Type | Outdoor Antenna Splitter |
| Number of Outputs | 4 |
| Input Connector | 1 × N-type female |
| Output Connectors | 4 × N-type female |
| Frequency Range | 800-3000 MHz |
| Insertion Loss | ~7 dB per path (typical) |
| Impedance | 50 Ω |
| Operating Power | ≤50 W |
| Housing Type | Weather-resistant enclosure |
| Mounting | Wall or mast mount |
| Operating Temp. | -30 °C to 70 °C |
| Weight | ~430 g |
