Detailed Specifications
A discreet omni-directional antenna for Wi-Fi 6E indoor deployments on ceilings.
Overview :
The HPE Aruba S1F82A is a tri-band, 4x4 cabled omni-directional antenna designed for indoor ceiling mounting. It provides reliable coverage across the full 2.4 GHz, 5 GHz, and 6 GHz Wi-Fi bands, including Wi-Fi 6E, with a low-profile, dual-polarized antenna array optimized for down-tilt deployment. This antenna helps ensure consistent wireless signal distribution throughout office spaces, classrooms, and other indoor environments. Designed specifically for deployment in suspended ceiling tiles, the S1F82A antenna offers uniform 360-degree horizontal coverage with focused vertical downtilt to minimize interference and maximize client connectivity below the ceiling. Its tri-band design supports simultaneous operation across Wi-Fi 6E's new 6 GHz band along with legacy 2.4 GHz and 5 GHz bands, enabling greater capacity and performance in dense client environments.
Features :
The antenna features four dual-polarized elements arranged to support 4x4 MIMO configurations, improving throughput and signal robustness. The RG58LL cables with RP-SMA male connectors provide secure, low-loss connections to Aruba access points. Its sturdy PC/ABS radome is UV-resistant for longevity in various indoor lighting conditions. With an IP20 indoor-use rating, this antenna maintains stable RF performance within climate-controlled environments. It includes mounting hardware compatible with standard ceiling tiles for straightforward installation and maintenance.
Product Key Features
Reliability & Performance :
With an IP20 indoor-use rating, this antenna maintains stable RF performance within climate-controlled environments. The downtilt omni pattern helps reduce co-channel interference while ensuring even coverage for clients below the antenna. It supports power input levels up to 2 Watts per port to accommodate high-output access points. The antenna includes mounting hardware compatible with standard ceiling tiles for straightforward installation and maintenance.
Key Features :
Specifications :
| Specification | Details |
|---|
| Brand | HPE Aruba |
| Model Number | S1F82A (AP-ANT-340) |
| Product Type | Tri-Band 4x4 Downtilt OmniCeilingAntenna |
| Frequency Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Polarization | Dual-polarized |
| MIMO Configuration | 4x4 MIMO |
| Beamwidth (Azimuth) | 360° |
| Beamwidth (Elevation) | 80° (2.4 GHz), 60° (5 GHz), 40° (6 GHz) |
| Maximum Input Power | 2 Watts per port |
| Connector Type | RP-SMA Male x4 with 75±1.8 cm cables |
| Radome Material | PC/ABS, UV resistant |
| Dimensions | 177.8 mm diameter x 32 mm height (antenna) |
| Weight | 0.4 kg |
| IP Rating | IP20 (Indoor) |
| Operating Temperature | -40°C to +70°C |
| Compatibility | HPE Aruba Access Points |
