Detailed Specifications
Netgear ANT2511AC-10000S Dual-Band Omni Antenna
Overview :
The Netgear ANT2511AC-10000S is an external omni-directional antenna intended to extend WiFi client reception for access points supporting external antennas. It offers operation across traditional 2.4 GHz and 5 GHz bands, improving signal coverage for connected devices. It is typically used in enterprise indoor or semi-outdoor locations where APs have removable antenna ports. The antenna integrates via RP-SMA plug connectors and works with compatible Netgear APs designed for optional external antennas.
Key Features :
Supports both 2.4 GHz and 5 GHz WiFi bands
3 dBi gain @ 2.4 GHz, 5 dBi gain @ 5 GHz
360° horizontal radiation pattern
RP-SMA plug (reverse polarity) connector
Technical Specifications :
| Specification | Value |
|---|
| Brand | Netgear |
| Part Number | ANT2511AC-10000S |
| Product Type | Dual-Band Omni Antenna |
| Wireless Standards | 802.11 a / b / g / n / ac |
| Frequency Range | 2.4–2.5 GHz and 4.9–5.85 GHz |
| Gain | 3 dBi at 2.4 GHz; 5 dBi at 5 GHz |
| Radiation Pattern | Horizontal 360°; Vertical 75° at 2.4 GHz, 22.5° at 5 GHz |
| Connector Type | RP-SMA plug |
| Operating Temperature | –20 °C to +60 °C |
| Dimensions | 185 × 36.2 × 12.7 mm |
| Weight | 0.025 kg |
