Overview
The Ubiquiti UACC-READER-PRO-AM-B Reader Pro Angle Mount is a black angled mounting accessory for UniFi Professional Access Readers. It positions a compatible access reader at a fixed 20° angle to improve the reader's mounting orientation and user interaction.
The mount is designed for wall installation and uses a polycarbonate enclosure. It is a mounting accessory only and does not include an access reader or provide access-control functionality by itself.
Mounting and Compatibility
The UACC-READER-PRO-AM-B is compatible with the UniFi UA-G2-Pro and UA-G3-Pro Professional Access Readers. Ubiquiti specifies wall mounting for the accessory and compatibility with the UA-G2-Pro gang box mount.
The fixed 20° angle changes the orientation of the installed reader rather than providing continuously adjustable positioning. This makes the accessory suitable where a fixed angled installation is required.
Key Features
- Fixed 20° angled mounting position
- Designed for UniFi Professional Access Readers
- Compatible with UA-G2-Pro and UA-G3-Pro
- Wall-mountable polycarbonate construction
- Black finish with compact 160 x 40.4 x 31.1 mm dimensions
Applications
The UACC-READER-PRO-AM-B is intended for UniFi Access installations where a Professional Access Reader needs to be mounted at a fixed 20° angle. It can be used with compatible readers in commercial, residential and other controlled-access installations where the mounting orientation requires adjustment.
DC Supplies Product Note
Confirm the reader model before ordering this accessory. Ubiquiti specifies compatibility with UA-G2-Pro and UA-G3-Pro. The UACC-READER-PRO-AM-B is a fixed-angle mounting accessory and should not be treated as a universal or adjustable reader mount.
Specifications
| Specification | Details |
|---|
| Brand | Ubiquiti |
| Part Number / MPN | UACC-READER-PRO-AM-B |
| Product Type | Reader Pro Angle Mount |
| Product Family | UniFi Access |
| Color | Black |
| Mounting Type | Wall |
| Mounting Angle | 20° |
| Enclosure Material | Polycarbonate |
| Dimensions | 160 x 40.4 x 31.1 mm (6.3 x 1.6 x 1.2 in) |
| Weight | 43 g (1.5 oz) |
| Compatible Reader | UA-G2-Pro |
| Compatible Reader | UA-G3-Pro |
| Gang Box Compatibility | UA-G2-Pro gang box mount |
FAQs
What is the UACC-READER-PRO-AM-B?
It is a 20° angled wall-mount accessory for compatible UniFi Professional Access Readers.
Which readers are compatible with this angle mount?
Ubiquiti specifies compatibility with the UA-G2-Pro and UA-G3-Pro Professional Access Readers.
What angle does the mount provide?
The mount provides a fixed 20° angle.
Can the angle be adjusted?
No. The UACC-READER-PRO-AM-B provides a fixed 20° mounting angle rather than a continuously adjustable angle.
What material is the mount made from?
The enclosure is made from polycarbonate.
Does this product include an access reader?
No. The UACC-READER-PRO-AM-B is a mounting accessory. The compatible access reader must be purchased separately.
