Ergotron 24-214-085 – WorkFit-C Dual Sit-Stand Workstation
Overview
The Ergotron 24-214-085 is a WorkFit-C Dual mobile sit-stand workstation designed for two LCD displays, keyboard and mouse operation, and a computer CPU. The black-and-grey cart combines a large worksurface, stowable keyboard tray, dual-monitor crossbar, CPU holder, cable management, and four dual-wheel casters for a mobile computing workstation.
Technical Information
The WorkFit-C uses Ergotron Constant Force lift technology to provide smooth height adjustment of the workstation. The height-adjustable assembly provides up to 25 inches (63 cm) of lift. The dual-monitor configuration supports two displays with a combined display weight of 12–28 lb (5.5–12.7 kg), with 360° display rotation and VESA MIS-D mounting.
Compatibility
The 24-214-085 supports two displays up to 24 inches each, with VESA 75 x 75 mm and 100 x 100 mm mounting patterns. The CPU holder accommodates computers from 9.4 x 2.6 x 15.75 inches to 15.75 x 8.5 x 40 inches (24 x 6.5 x 40 cm, depending on orientation and holder dimensions). The workstation is intended for mobile floor-standing deployment and includes two locking casters.
Key Features
- Dual-monitor WorkFit-C sit-stand workstation configuration
- 25-inch (63 cm) height adjustment with Constant Force lift technology
- Supports two LCD displays up to 24 inches with 12–28 lb combined display weight
- Large worksurface with stowable keyboard tray and integrated cable storage
- Mobile four-caster base with two locking casters and integrated CPU holder
Applications
The workstation is suited to mobile computing environments where users need to alternate between seated and standing positions while operating two displays. Its mobile cart format supports office, healthcare, collaborative, and other professional workstation deployments where equipment must be moved between locations.
DC Supplies Product Note
Verify the combined weight and VESA pattern of both displays before installation. The 24-214-085 is specifically the WorkFit-C Dual configuration and includes the dual-monitor crossbar, two LCD mounts, CPU holder, worksurface, keyboard tray, cable management components, and mobile caster base.
Specifications
| Specification | Details |
|---|
| Brand | Ergotron |
| Part Number / MPN | 24-214-085 |
| Product Type | Dual-Monitor Mobile Sit-Stand Workstation |
| Product Series | WorkFit-C |
| Color | Black and Grey |
| Monitor Configuration | Dual LCD |
| Maximum Monitor Size | 24 inches per display |
| Combined Display Capacity | 12–28 lb (5.5–12.7 kg) |
| Height Adjustment | 25 inches (63 cm) |
| Monitor Rotation | 360° |
| VESA Mounting | MIS-D, 75 x 75 mm and 100 x 100 mm |
| CPU Holder Capacity | 40 lb (18 kg) |
| Worksurface | 24 x 23 inches (61 x 58 cm) |
| Keyboard Tray | 26.3 x 9.4 inches (67 x 24 cm) |
| Base | Four dual-wheel casters |
| Locking Casters | 2 |
| Technology | Constant Force lift |
| Cable Management | Integrated cable storage box and CPU holder cable management |
| Warranty | 5 years |
FAQs
How many monitors does the Ergotron 24-214-085 support?
The WorkFit-C Dual configuration supports two LCD displays mounted side by side on its dual-monitor crossbar.
What monitor size is supported?
Ergotron specifies displays up to 24 inches for the 24-214-085 configuration.
What is the combined monitor weight capacity?
The two displays have a combined supported weight range of 12–28 lb (5.5–12.7 kg).
Does the workstation support VESA mounting?
Yes. The included monitor mounts support VESA MIS-D patterns of 75 x 75 mm and 100 x 100 mm.
Is the WorkFit-C Dual workstation mobile?
Yes. It uses four dual-wheel casters, including two locking casters, allowing the workstation to be moved and secured at the required location.
Does the 24-214-085 include a CPU holder?
Yes. The WorkFit-C Dual configuration includes a CPU holder with a specified capacity of up to 40 lb (18 kg).
