HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable View larger

HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable

JL356A

New

In Stock

HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable

×




Ethernet Switch, HPE Aruba switch, HPE Aruba 2540 Switch, dc supplies, 24 ports switch, aruba 24 port switch, aruba 24 port gigabit switch, HPE JL356A, JL356A, 2540 24G PoE switch, 24g poe 4sfp switch, JL356A ethernet switch

$1,600.00

Detailed Specifications

HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable

Overview:

The HPE Aruba JL356A 2540 24G PoE+ 4SFP+ Switch is expertly designed to meet the dynamic needs of today's digital workplaces. This Layer 2 access switch from the Aruba 2540 Switch Series is optimized for mobile users, offering advanced security and network management tools like Aruba ClearPass Policy Manager and Aruba AirWave. These tools ensure a secure and efficient networking environment, making the JL356A an ideal choice for a variety of environments, including enterprise campuses, small and medium-sized businesses (SMBs), and branch offices.

The switch supports cloud-based management via Aruba Central, allowing for seamless deployment and management, especially in remote branch sites with minimal IT intervention. This feature makes it easy to set up and manage networks without the need for extensive technical expertise on-site.

The Aruba 2540 series is packed with features that enhance network performance and reliability. It includes built-in 10GbE uplinks, robust Quality of Service (QoS) capabilities, and support for static and RIP routing. The switch is also IPv6 compatible and comes in Power over Ethernet Plus (PoE+) models, making it versatile and suitable for various applications. Additionally, it requires no additional software licensing, simplifying the procurement process and providing a cost-effective networking solution.

Specifications :

SpecificationDetails
Model JL356A
Ports 24 RJ-45 autosensing 10/100/1000 PoE+ ports, 4 SFP+ 1/10GbE ports
Additional Ports and Slots 1 dual-personality (RJ-45 or USB micro-B) serial console port
Memory and Processor Dual Core ARM Cortex A9 @ 1016 MHz, 1 GB DDR3 SDRAM
Packet Buffer Size 12.38 MB (4.5 MB Ingress, 7.785 MB Egress)
Storage 4 GB eMMC
Dimensions (HxWxD) 4.39 cm x 44.42 cm x 30.42 cm (1.73” x 17.42” x 11.98”) (1U height)
Throughput Up to 95.2 Mpps
Switching Capacity 128 Gbps
Energy Efficiency Yes
Environmentally Friendly Yes
Operating Temperature Range 0°C to 45°C (32°F to 113°F)
Storage Temperature Range -40°C to 70°C (-40°F to 158°F)
Humidity 15% to 95% non-condensing
Compliance Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3at
