HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable View larger

HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable



HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable


HPE Aruba switch, HPE Aruba 2540 Switch, dc supplies, aruba 24 port switch, aruba 24 port gigabit switch, HPE JL356A, JL356A, 2540 24G PoE switch, 24g poe 4sfp switch, aruba 2540 switch series, JL356A ethernet switch

Detailed Specifications

HPE Aruba JL356A 2540 24G PoE+ 4SFP+24 ports Managed Rack Mountable


The HPE Aruba JL356A is tailored to meet the demands of today's digital workplaces, while the Aruba 2540 Switch Series is specifically optimized to cater to the needs of mobile users. Equipped with advanced security and network management tools such as Aruba ClearPass Policy Manager and Aruba AirWave, this Layer 2 access switch ensures a secure and efficient networking environment. Its seamless deployment and management are further facilitated by support from the cloud-based Aruba Central platform, enabling rapid setup of remote branch sites with minimal IT intervention. The 2540 series is well-suited for a variety of environments, including enterprise campuses, small and medium-sized businesses (SMBs), and branch offices, offering entry-level features that include built-in 10GbE uplinks, robust Quality of Service (QoS) capabilities, static and RIP routing support, IPv6 compatibility, and Power over Ethernet Plus (PoE+) models. Notably, these switches require no additional software licensing, simplifying the procurement process and providing cost-effective networking solutions for organizations of all sizes.

Specifications :




24 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE- TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 4 SFP+ 1/10GbE ports; PHY-less

Additional ports and slots

1 dual-personality (RJ-45 or USB micro-B) serial console port

Memory and processor

Dual Core ARM Coretex A9 @ 1016 MHz, 1 GB DDR3 SDRAM

Packet buffer size: 12.38 MB

4.5 MB Ingress/7.785 MB Egress, 4 GB eMMC


(H) 4.39 cm x (W) 44.42 cm x (D) 30.42 cm (1.73” x 17.42” x 11.98”) (1U height)


up to 95.2 Mpps

Switching capacity

128 Gbps
